Oil Pan for 1991-2000 Ford Explorer & More - Agility 3310239

$241.99

Vehicles this part fits

    Part number: 3310239
    UPC: 887548387387
    Condition: New
    Weight: 15.71 LBS
    Item Package Quantity: 1
    $241.99
    Adding to cart… The item has been added

    Have questions?

    Agility Autoparts Engine Oil Pan P/N:3310239
    Agility Autoparts Engine Oil Pan P/N:3310239
    $241.99
    $241.99

    Agility 3310239 oil pan for the 1991-2000 Ford Explorer V6 4.0L and other vehicles collects and holds the engine oil at the bottom of the engine. The pan is engineered to satisfy every OEM specification.

    • Aluminum pan body
    • Baffled design
    • Drain plug included with the pan

    Quick facts

    • Part: Agility 3310239 oil pan
    • Also called: engine oil pan
    • Fits: 1991-2000 Ford Explorer V6 4.0L and other vehicles
    • Material: Aluminum
    • Condition: New

    Oil drips under the engine, a dented or cracked pan, or damaged drain threads can mean the pan needs replacing. Before you replace it, rule out a loose drain plug or a leak from another part, because oil on the ground can have more than one source. Each V6 4.0L takes a single pan.

    Fits

    It is a direct-fit oil pan for the 1990-2000 Ford Ranger V6 4.0L, the 1991-2000 Ford Explorer V6 4.0L and the 1990-1997 Ford Aerostar V6 4.0L.

    Specifications

    Fit and size

    • Quantity per vehicle: 1
    • Drain thread size: M14 x 1-1/2

    Build and materials

    • Material: Aluminum
    • Baffled: Yes
    • Drain plug: included
    • Windage tray: not included
    • Condition: New
    • Country of origin: China

    In the box

    One oil pan with its drain plug. A windage tray is not included.

    Interchange: 264-054 · 311-00771B · 311-00771C
    F4TZ6675B · F5TZ6675B · FP63A

    Product information is for general reference and may contain errors. See our Disclaimer.

    This part cross-references / interchanges with the following part numbers:

    264-054, F4TZ6675B, F5TZ6675B, 311-00771B, 311-00771C, FP63A

    Frequently Asked Questions

    Does the Agility 3310239 oil pan fit the 1991-2000 Ford Explorer V6 4.0L?

    Yes. Agility 3310239 is a direct-fit oil pan for the 1991-2000 Ford Explorer V6 4.0L, and each engine takes one pan.

    Does the Agility 3310239 oil pan come with a drain plug?

    Yes, the drain plug is included, with an M14 x 1-1/2 drain thread; a windage tray is not included.

    Is this engine oil pan aluminum and baffled?

    Yes. Agility 3310239 is made of aluminum and is baffled.

    How can I tell if my aluminum oil pan is leaking?

    Oil spots where you park, or oil seen seeping around the bottom of the engine, can be signs. A shop can confirm whether the pan is the source of the leak.

    Does Agility 3310239 interchange with part number F4TZ6675B?

    Yes. F4TZ6675B is one of the numbers this oil pan replaces, along with 264-054 and 311-00771B.
