Radiator for 1996 Chevrolet Express 2500 & More - Agility 8011538

$195.99

Part number: 8011538

UPC: 887548032683

Condition: New

Weight: 42.68 LBS

Item Package Quantity: 1

$195.99

Current Stock: 9

Quantity:

Adding to cart… The item has been added

Have questions?

Ask an Expert

Agility Autoparts Radiator P/N:8011538

$195.99

Description

Agility 8011538 radiator for the 1996 Chevrolet Express 2500 V8 6.5L and other vehicles carries engine coolant through its core so the heat can leave the engine.

Plastic tank and aluminum construction
Two-row core for the coolant-to-air heat exchange
Every radiator is 100% leak tested
Certified to meet or exceed the manufacturer's specifications and ready to install out of the box

Quick facts

Part: Agility 8011538 radiator
Fits: 1996 Chevrolet Express 2500 V8 6.5L and other vehicles
Condition: New

Coolant stains under the vehicle, a coolant level that keeps dropping or an engine that runs hot can mean the radiator is worn, but a failing thermostat or water pump may be the source instead. Find the cause first, then replace the radiator if it is at fault.

Fits

This radiator is also a direct-fit replacement for the 1996 Chevrolet Express 3500 V8 6.5L and the 1994-1996 Chevrolet G30 V8 6.5L. Driving something else? Run your year and model through the "Vehicles it fits" section.

Specifications

Fit and size

Quantity per vehicle: 1
Core height: 17.25 in
Core width: 32 in
Core thickness: 2.125 in
Core rows: 2
Inlet diameter: 1.75 in
Outlet diameter: 1.75 in
Transmission oil cooler length: 11.5 in
Engine oil cooler length: 11.5 in

Build and materials

Construction: plastic tank, aluminum
Condition: New
Country of origin: China

In the box

This listing is one radiator, and the vehicle takes one.

Interchange: 41-1538
20718 · 1538 · CRS1538 · RA1066 · 52461815 · CU1538 · 431332

Manufacturer's description

Product specs

Vehicles it fits

Interchange numbers

This part cross-references / interchanges with the following part numbers:

20718, 1538, CRS1538, RA1066, 52461815, 41-1538, CU1538, 431332

Buyer's Q&A

Frequently Asked Questions

Is Agility 8011538 the right G30 radiator for a 1994-1996 Chevrolet V8 6.5L?

Yes. Agility 8011538 is listed for the 1994-1996 Chevrolet G30 V8 6.5L, and the vehicle takes one radiator.

What size are the inlet and outlet on this Agility radiator?

Both the inlet and the outlet are 1.75 inches in diameter. The core measures 32 inches wide, 17.25 inches high and 2.125 inches thick.

Is the Agility 8011538 radiator plastic or aluminum?

It has a plastic tank and aluminum construction, with a two-row core.

Can I spot a failing radiator just by looking at the tank and core?

With the engine off and cool, look for coolant stains, crusty residue or cracks at the tank and core seams. These can mean a leak, and a shop can pressure-test the cooling system.

Does Agility 8011538 interchange with CRS1538?

Yes. CRS1538 is one of the numbers Agility 8011538 replaces, along with 41-1538 and RA1066.
