Air Suspension System for 2010-2017 Harley-Davidson Fxdwg Dyna Wide Glide & More - Arnott MC-3104

$753.99

Vehicles this part fits

    Part number: MC-3104
    UPC: 815710015943
    Condition: New
    Weight: 16.30 LBS
    Item Package Quantity: 1
    $753.99
    Adding to cart… The item has been added

    Have questions?

    Arnott Industries Air Suspension System P/N:MC-3104
    Arnott Industries Air Suspension System P/N:MC-3104
    $753.99
    $753.99

    Arnott MC-3104 air suspension system for the 2010-2017 Harley-Davidson Fxdwg Dyna Wide Glide and other vehicles raises and lowers the bike with an onboard compressor and switch. This Arnott air suspension for your motorcycle suits shorter riders and riders with mobility issues, and it lowers the bike for a slammed look while parked.

    • Arnott Smooth Ride Series adjustable kit with an onboard compressor and micro-toggle inflation switch
    • Over 3" of travel, controlled from the onboard toggle switch
    • Two custom-valved 13" nitrogen-charged mono-tube shock absorbers with an Internal Floating Piston that separates gas from oil
    • Goodyear air spring sleeves, with ride height set to your weight, size, road conditions and riding preference
    • Thomas High Output Compressor with an application-specific bracket
    • Aircraft-quality billet aluminum construction

    Quick facts

    • Part: Arnott MC-3104 air suspension system
    • Fits: 2010-2017 Harley-Davidson Fxdwg Dyna Wide Glide and other vehicles
    • Condition: New

    A bike that sags, rides harshly or loses air pressure can mean worn shocks or a leaking air spring. These signs alone do not prove this system is the problem; a low tire is another common cause. This listing is one complete system, with one shock on each side of the bike.

    Fits

    The 2010-2017 Harley-Davidson Fxdwg Dyna Wide Glide, the 2008-2017 Harley-Davidson Fxdb Street Bob and the 2008-2017 Harley-Davidson Fxdf Fat Bob take this system, and so do other models. Open the "Vehicles it fits" section to check your exact model and year.

    Specifications

    Fit and size

    • Quantity per application: 1
    • Shock absorbers: two, 13"
    • Travel: over 3"

    Build and materials

    • Type: adjustable air suspension kit with onboard compressor and toggle switch
    • Shock type: nitrogen-charged mono-tube with Internal Floating Piston
    • Air spring sleeves: Goodyear
    • Compressor: Thomas High Output
    • Construction: aircraft-quality billet aluminum
    • Condition: New
    • Country of origin: United States

    In the box

    One air suspension system with two shock absorbers, a compressor with its mounting bracket, an air distribution valve block with muffler, a fused wiring harness and relay assembly, tubing, cable ties, fittings, bolt covers, protective aluminum covers, mounting accessories and a user manual.

    Installation notes

    • A user manual comes with the kit.
    • Detailed installation instructions are available.

    Product information is for general reference and may contain errors. See our Disclaimer.

    Frequently Asked Questions

    Is this Arnott air suspension for Harley-Davidson bikes right for the 2008-2017 Harley-Davidson Fxdb Street Bob?

    Yes. Arnott MC-3104 fits the 2008-2017 Harley-Davidson Fxdb Street Bob. If your bike is another model, look it up in the "Vehicles it fits" section.

    Does the Arnott air suspension Harley kit include a compressor?

    Yes. Arnott MC-3104 comes with a compressor and bracket, two shocks, an air distribution valve block, a fused wiring harness and relay assembly, tubing, fittings and a user manual.

    What size are the shocks in this Arnott air suspension system?

    The system has two custom-valved 13" nitrogen-charged mono-tube shock absorbers. An Internal Floating Piston separates the gas from the oil.

    Does the Arnott MC-3104 come with installation instructions?

    Yes. A user manual comes with the kit, and detailed installation instructions are available. The kit also includes the wiring harness, tubing and fittings.

    How much can this air suspension raise or lower the bike?

    The system gives over 3" of travel. The onboard toggle switch raises or lowers the bike, so a rider can rest flat-footed while stopped or parking.
