Air Suspension System for 2007 Harley-Davidson Fxdc Super Glide Custom & More - Arnott MC-3105

$741.99

Vehicles this part fits

    Part number: MC-3105
    UPC: 815710015950
    Condition: New
    Weight: 16.40 LBS
    Item Package Quantity: 1
    $741.99
    Adding to cart… The item has been added

    Have questions?

    Arnott Industries Air Suspension System P/N:MC-3105
    Arnott Industries Air Suspension System P/N:MC-3105
    $741.99
    $741.99

    Arnott MC-3105 air suspension system for the 2007 Harley-Davidson Fxdc Super Glide Custom and other vehicles lets you raise or lower the bike with an onboard compressor. It delivers load-leveling and ride comfort, with a height you set for your weight, size, road conditions and riding preference.

    • Arnott Smooth Ride Series adjustable air suspension kit
    • Two custom-valved 13-inch nitrogen-charged mono-tube shocks with a floating piston that separates gas from oil
    • Goodyear air spring sleeves for added strength and extended service life
    • Thomas High Output Compressor with application-specific bracket
    • Micro-toggle inflation switch raises or lowers the bike, with over 3 inches of travel
    • Crafted from aircraft-quality billet aluminum for strength and precision

    Quick facts

    • Part: Arnott MC-3105 air suspension system
    • Fits: 2007 Harley-Davidson Fxdc Super Glide Custom and other vehicles

    A bike that sags, rides harshly or has oil seeping from a shock can have a worn suspension. Before you replace the kit, rule out a loose air fitting or a blown fuse in the wiring, since either one can also leave the bike unable to hold its height.

    Fits

    The 2007 Harley-Davidson Fxdc Super Glide Custom, the 1995-2005 Harley-Davidson FXD Dyna Super Glide and the 1993-2005 Harley-Davidson Fxdl Dyna Low Rider are among the bikes this kit fits, and it fits many more.

    Specifications

    Fit and size

    • Quantity per vehicle: 1
    • Shock size: 13 in
    • Travel: over 3 in

    Build and materials

    • Shocks: nitrogen-charged mono-tube with an internal floating piston (IFP)
    • Air spring: Goodyear air spring sleeves
    • Compressor: Thomas High Output Compressor with application-specific bracket
    • Switch: micro-toggle inflation switch
    • Construction: crafted from aircraft-quality billet aluminum
    • Country of origin: United States

    In the box

    One air suspension kit with two 13-inch shocks, Goodyear air spring sleeves, a Thomas compressor with its bracket, an air distribution valve block with a muffler, a fused wiring harness and relay assembly, tubing, cable ties, fittings, bolt covers, protective aluminum covers and mounting accessories. This listing holds one kit, which is the amount one bike takes.

    Installation notes

    • A user manual comes with the kit, and detailed installation instructions are available.

    Product information is for general reference and may contain errors. See our Disclaimer.

    Frequently Asked Questions

    Is this Arnott air suspension for Harley-Davidson a fit for the 1995-2005 Harley-Davidson FXD Dyna Super Glide?

    Yes. Arnott MC-3105 fits the 1995-2005 Harley-Davidson FXD Dyna Super Glide. If your bike is not named here, look up its year and model in the "Vehicles it fits" section on this page.

    What comes with the Arnott air suspension on a Harley?

    Arnott MC-3105 includes two 13-inch shocks, Goodyear air spring sleeves, a Thomas compressor with bracket, a valve block, a fused wiring harness with relay, tubing, fittings, cable ties, covers and a user manual.

    How much travel does the Arnott motorcycle air suspension give?

    The kit gives over 3 inches of travel. The onboard toggle switch raises or lowers the bike so it can rest flat-footed while stopped.

    Does this air suspension kit come with a user manual?

    Yes, a user manual comes with the kit. Detailed installation instructions are also available.

    Which compressor does this air suspension system use?

    This air suspension system uses a Thomas High Output Compressor with an application-specific bracket. The valve block includes a muffler that controls how fast air is released.
