Direct Injection High Pressure Fuel Pump for 2014-2018 Volkswagen Jetta & More - Bosch 66830

$533.99

Vehicles this part fits

    Part number: 66830
    UPC: 077212260003
    Condition: New
    Weight: 2.20 LBS
    Item Package Quantity: 1
    $533.99
    Adding to cart… The item has been added

    Have questions?

    Bosch Direct Injection High Pressure Fuel Pump P/N:66830
    Bosch Direct Injection High Pressure Fuel Pump P/N:66830
    $533.99
    $533.99

    Bosch 66830 direct injection high pressure fuel pump for the 2014-2018 Volkswagen Jetta 4-cylinder 1.8L or 2.0L and other vehicles sends fuel at high pressure to the injectors of a gasoline direct injection engine. It is a mechanical piston pump, sold as a single pump.

    • Designed to operate in extreme temperatures and low fuel conditions
    • End-of-line function testing on every pump before it leaves the manufacturing facility
    • Steel construction with an integrated pressure limiter valve
    • Compact, light-weight design with an integrated pressure damper capable of variable feed pressure
    • On-demand quantity control for minimized fuel consumption, increased torque and fewer carbon emissions

    Quick facts

    • Part: Bosch 66830 direct injection high pressure fuel pump
    • Fits: 2014-2018 Volkswagen Jetta 4-cylinder 1.8L or 2.0L and other vehicles
    • Material: Steel
    • Condition: New

    Hard starting, rough running or a drop in power can mean a high pressure pump is wearing out. These signs alone do not prove the pump is at fault, since a faulty fuel pressure sensor could produce similar symptoms.

    Fits

    This pump is listed for a wide range of Volkswagen models, including the 2014-2017 Volkswagen Passat 4-cylinder 1.8L and the 2015-2018 Volkswagen Golf 4-cylinder 1.8L. The quantity is one pump per engine. If your car is not named here, search the "Vehicles it fits" section for your own year, model and engine.

    Specifications

    Fit and size

    • Quantity per vehicle: 1
    • Outside diameter: 16 mm
    • Inside diameter: 6 mm
    • Housing width: 51 mm
    • Inlet size: 9 mm
    • Outlet size: 14 mm
    • Outlet thread: M16 x 1.5

    Build and materials

    • Material: Steel
    • Pump type: Mechanical, piston
    • Fuel type: Gasoline
    • Mounting: External
    • Seal: O-ring, synthetic or NBR rubber
    • Condition: New

    In the box

    One direct injection high pressure fuel pump with an O-ring. A lock ring and a wire harness are not included.

    Installation notes

    • Designed for plug-and-play installation.
    • Made in-house rather than sourced or reverse-engineered, for a direct-fit installation.

    Interchange: 06A127026H

    Product information is for general reference and may contain errors. See our Disclaimer.

    This part cross-references / interchanges with the following part numbers:

    06A127026H

    Frequently Asked Questions

    Is the Bosch 66830 pump right for a 2014-2018 Volkswagen Jetta 4-cylinder 1.8L or 2.0L?

    Yes. Bosch 66830 is listed for the 2014-2018 Volkswagen Jetta with either the 1.8L or the 2.0L 4-cylinder, and each of those engines takes one pump.

    Does the Bosch 66830 come with an O-ring?

    Yes. The package holds one high pressure pump with an O-ring. A lock ring and a wire harness are not included.

    What size are the outlet and inlet on this GDI fuel pump?

    The outlet on this direct injection high pressure fuel pump is 14 mm with an M16 x 1.5 thread, and the inlet is 9 mm.

    How can I tell if a high pressure fuel pump on a direct injection engine is failing?

    Hard starting, rough running or a loss of power can be signs of a worn pump. A shop can test the fuel pressure to find out.

    Is each Bosch 66830 pump function tested?

    Yes. Every Bosch 66830 pump goes through an end-of-line function test before leaving the manufacturing facility.
