Bosch 67684 fuel pump module for the 2002-2003 Dodge Ram 1500 V6 3.7L, V8 4.7L or 5.9L moves fuel from the tank to the injection system. This new Bosch fuel pump module assembly is an electric pump unit that sits inside the tank.
- Patented Turbine Pump technology that virtually eliminates fuel pulsation, noise and hot-start problems of older pump designs
- Designed to operate in extreme temperatures and under low fuel conditions
- End-of-line function test on every pump
- Two layers of filtration protect the pump from debris and fuel system contamination
- Electromagnetic shielding prevents on-board electronic interference from the fuel pump
- Demand-controlled operation delivers only the amount of fuel the injection system requires
Quick facts
- Part: Bosch 67684 fuel pump module
- Also called: fuel pump assembly
- Fits: 2002-2003 Dodge Ram 1500 V6 3.7L, V8 4.7L or 5.9L
- Material: Mixed
- Condition: New
Hard starting, stalling or a whine from the fuel tank can mean the pump is wearing out. Before you replace the module, rule out a blown fuse, a faulty relay or damaged wiring, since each of those can also keep the pump from running. A shop can test the fuel system for you.
Fits
This listing is one module and a direct-fit replacement for the 2002-2003 Dodge Ram 1500 V6 3.7L, V8 4.7L or 5.9L; the truck takes one.
Specifications
Fit and size
- Quantity per vehicle: 1
- Mounting type: In-tank
- Inlet and outlet outside diameter: 11.1 mm each
- Inside diameter: 6 mm
- Voltage: 12 V DC
- Terminals: 4 blade terminals, 1 square/rectangle connector
Build and materials
- Type: Module, electric pump design, fuel injection delivery
- Material: Mixed
- Housing material: Polymer / plastic
- Gasket or seal material: Synthetic or NBR rubber
- Condition: New
- Country of origin: United States
In the box
One module assembly with the fuel sending unit, strainer, filter, regulator, gasket or seal and O-ring. Mounting hardware, lock ring, suction pipe and wiring harness are not included, so plan on new hardware.
Installation notes
- Designed for simple plug-and-play installation.
Interchange: 5072764AD
Product information is for general reference and may contain errors. See our Disclaimer.
Frequently Asked Questions
Is Bosch 67684 the right fuel pump module assembly for the 2002-2003 Dodge Ram 1500 with the V6 3.7L, V8 4.7L or 5.9L?
Yes. Bosch 67684 fits the 2002-2003 Dodge Ram 1500 with the V6 3.7L, V8 4.7L or 5.9L, and the truck takes one module.
Does the Bosch fuel pump module come with the sending unit and strainer?
Yes. Bosch 67684 includes the fuel sending unit, strainer, filter, regulator, gasket or seal and O-ring. The lock ring, wiring harness and mounting hardware are not included.
Is this Bosch fuel pump assembly a full module or just the pump?
This Bosch module is a full module, not a pump only: an electric in-tank unit that runs on 12 V DC and has one outlet with an 11.1 mm outside diameter.
Can a worn Bosch 67684 fuel pump module cause hard starting or sputtering?
Yes, it can if the pump is the cause. Hard starting, sputtering and a whine from the tank can all mean a worn pump; have the fuel system checked promptly.
How long is a Bosch fuel pump module tested to last?
Bosch aftermarket fuel pumps are tested to a minimum lifetime of 150k miles, and every Bosch fuel pump gets an end-of-line function test.
