Rear Left CV Axle for 2003-2006 Ford Expedition & More - CARDONE New 66-2160

$183.99

Vehicles this part fits

    Part number: 66-2160
    UPC: 884548260917
    Condition: New
    Weight: 28.80 LBS
    Sold as: 1 per side
    $183.99
    Adding to cart… The item has been added

    Have questions?

    CARDONE New CV Axle Assembly P/N:66-2160
    CARDONE New CV Axle Assembly P/N:66-2160
    $183.99
    $183.99

    CARDONE New 66-2160 rear left CV axle for the 2003-2006 Ford Expedition and other vehicles carries drive torque to the wheel hub and flexes with suspension travel. The CV axle assembly comes complete with both CV joints.

    • Neoprene boots with extra bellows, when needed, to resist bellow stress and cracking
    • Shaft checked individually for straightness, for vibration-free running at all speeds
    • Boot clamps pneumatically crimped to seal each boot to its housing
    • Grease that withstands high-temperature and high-torque demands
    • Splines and threads precision rolled to fit the hub, the transmission and the axle nut
    • Transmission seal diameter precision-machined after heat treatment for the correct surface finish

    Quick facts

    • Part: CARDONE New 66-2160 CV axle
    • Also called: CV axle assembly
    • Fits: 2003-2006 Ford Expedition and other vehicles
    • Position: Rear left
    • Material: Steel shaft, neoprene boots
    • Condition: New

    A clicking or snapping noise when you turn hard under throttle, grease on the chassis or suspension, or a vibration when accelerating can mean an axle is worn or a boot has split. These signs alone do not prove the axle is at fault, since a worn wheel bearing can make similar noise.

    Fits

    It fits the 2003-2006 Ford Expedition and the 2003-2006 Lincoln Navigator. This listing is one axle for the rear left; the rear right is a separate part, and the two sides of that axle are normally done together. The vehicle takes one on each side.

    Specifications

    Fit and size

    • Position: rear left
    • Quantity: 1 per side
    • Shaft diameter: 32 mm (1.26 in)
    • Compressed length: 917 mm (36.102 in)
    • Axle nut thread: M24x2.0, hex
    • Axle nut socket size: 35 mm (1.378 in)
    • Splines: 34 inboard, 33 outboard

    Build and materials

    • Shaft material: steel
    • Boot material: neoprene, 5 ribs
    • Inboard and outboard joints: splined
    • ABS tone ring: not included
    • Condition: New
    • Country of origin: China

    In the box

    One CV axle with both CV joints, one new axle retaining nut and an instruction sheet.

    Installation notes

    • Fit the supplied new retaining nut and discard the old one.
    • Tighten the nut with a torque wrench to the manufacturer's specification, never an impact wrench.
    • Remove and install one axle at a time, and do not leave it hanging unsupported.
    • If the old stub shaft is stuck in the hub, use a press-type tool and do not strike it with a hammer.

    Interchange: 4L1Z4K139AA · 4L1Z4K139AB · 4L1Z4K139AC

    Product information is for general reference and may contain errors. See our Disclaimer.

    This part cross-references / interchanges with the following part numbers:

    4L1Z4K139AA, 4L1Z4K139AB, 4L1Z4K139AC

    Frequently Asked Questions

    Does the CARDONE New 66-2160 fit the 2003-2006 Lincoln Navigator?

    Yes. CARDONE New 66-2160 is a rear left CV axle for the 2003-2006 Lincoln Navigator, and it also fits the 2003-2006 Ford Expedition.

    Does the CARDONE 66-2160 come with an axle nut and CV joints?

    Yes. CARDONE New 66-2160 includes a new axle retaining nut, both CV joints and an instruction sheet. The ABS tone ring is not included.

    What size is the axle nut on this CV axle?

    The hex axle nut has an M24x2.0 thread and takes a 35 mm socket. It is 22 mm long.

    How can I tell if a rear CV axle boot has failed?

    A split or cracked boot, or grease thrown onto nearby chassis and suspension parts, can mean the boot has ruptured. Clicking on hard turns can also come from a worn outer joint.

    Can I use an impact wrench on the nut of this CV axle?

    No. Use a torque wrench and tighten the nut to the manufacturer's specification. Work on one axle at a time.
