Front Left CV Axle for 2014-2015 BMW X5 & More - A1 CARDONE 66-9766

$166.99
Sold out

Vehicles this part fits

    Part number: 66-9766
    UPC: 884548300422
    Condition: New
    Weight: 16.30 LBS
    Item Package Quantity: 1
    $166.99

    Out of stock

    Have questions?

    CARDONE New CV Axle Assembly P/N:66-9766
    CARDONE New CV Axle Assembly P/N:66-9766
    $166.99
    $166.99

    A1 CARDONE 66-9766 front left CV axle for the 2014-2015 BMW X5 and other vehicles sends drive torque from the transmission to the wheel. This new CV axle assembly comes with both CV joints and a new axle retaining nut.

    • Neoprene boots with additional bellows, when needed, to resist bellow stress and cracking, the leading cause of boot failure
    • Each shaft individually verified for straightness, for vibration-free performance at all speeds
    • Boot clamps pneumatically crimped to seal the boot to the housing
    • High-quality grease that withstands high temperature and high torque
    • Precision-rolled splines and threads for a proper fit in the hub, transmission and axle nut
    • Transmission seal diameter precision-machined after heat treatment, for a surface finish that promotes long seal life

    Quick facts

    • Part: A1 CARDONE 66-9766 CV axle
    • Also called: CV axle assembly
    • Fits: 2014-2015 BMW X5 and other vehicles
    • Position: Front left
    • Material: Steel shaft, neoprene boots
    • Condition: New

    Clicking when you turn under power, a thump or vibration on acceleration, or grease thrown onto the chassis and suspension can mean a worn joint or a torn boot. Before you replace the axle, rule out other causes of the same signs, such as a broken engine mount that lets the drivetrain shift out of alignment. This listing is one front left axle; the front right is a separate part, and the two are normally replaced together.

    Fits

    This CV axle fits the 2014-2015 BMW X5 and the 2015 BMW X6.

    Specifications

    Fit and size

    • Position: Front left
    • Quantity per application: 1
    • Shaft diameter: 28 mm (1.102 in)
    • Compressed length: 665 mm (26.181 in)
    • Inboard joint: splined, 27 splines
    • Outboard joint: splined, 30 splines
    • Axle nut thread: M27x1.5
    • Axle nut socket size: 36 mm (1.417 in)

    Build and materials

    • Shaft material: Steel
    • Boot material: Neoprene, 5 ribs
    • CV joints: included
    • Axle nut: hex, included
    • ABS tone ring: not included
    • Condition: New
    • Country of origin: China

    In the box

    One complete CV axle, a new hex axle retaining nut and an instruction sheet. This listing holds one axle, and the front left takes one.

    Installation notes

    • A new axle retaining nut is supplied, since the original nut is often worn or stripped.
    • Remove and install one axle at a time, and install new transaxle seals to avoid leaking.
    • Tighten the retaining nut with a torque wrench to the vehicle's specification, never an impact wrench.

    Interchange: 31608631747

    Product information is for general reference and may contain errors. See our Disclaimer.

    This part cross-references / interchanges with the following part numbers:

    31608631747

    Frequently Asked Questions

    Is this a BMW X5 CV axle for 2014-2015 models, and does it also fit the 2015 BMW X6?

    Yes, A1 CARDONE 66-9766 is a front left CV axle for the 2014-2015 BMW X5 and the 2015 BMW X6; the front right side is a separate part.

    Does the A1 CARDONE CV axle come with a new axle nut?

    Yes, A1 CARDONE 66-9766 includes the complete axle, a new hex axle nut and an instruction sheet; the ABS tone ring is not included.

    What are the spline counts and shaft diameter on this A1 CARDONE CV drive axle?

    The inboard joint has 27 splines and the outboard joint has 30. The shaft is 28 mm (1.102 in) in diameter, with a compressed length of 665 mm.

    Are the boots on A1 CARDONE axles neoprene?

    Yes. The boots on this A1 CARDONE 66-9766 axle are neoprene, with additional bellows when needed to resist bellow stress and cracking.

    Can I reuse the old locking nut or use an impact wrench on this CV axle?

    No: never reuse a prevailing torque lock nut, so use the new nut supplied, and tighten it with a torque wrench, not an impact wrench.
