CARDONE 96-5844 power steering pump for the 1988-1995 Toyota 4Runner and other vehicles builds the hydraulic pressure that gives the steering its power assist. It is designed to fit and perform like the original and meets or exceeds O.E. performance.
- High-temperature seals supplied with each pump for reliability
- Computer load testing that builds real-world parameters into the test cycle
- Precise bushing alignment limits premature shaft and seal wear and reduces noise and vibration
- Cast iron housing
Quick facts
- Part: CARDONE 96-5844 power steering pump
- Fits: 1988-1995 Toyota 4Runner and other vehicles
- Material: Cast iron housing
- Condition: New
A constant whine, steering that feels heavy or vibration through the wheel can mean the pump is worn, though a binding steering component or contamination in the fluid system can be behind them as well, so trace the cause before swapping the pump.
Fits
It is a power steering pump for the 1988-1995 Toyota 4Runner, which takes one, and for the 1988-1995 Toyota Pickup, which also takes one.
Specifications
Fit and size
- Quantity per vehicle: 1
- Outlet thread size: 16x1.5
- Hose port type: O-ring
- Inlet attachment type: Barb
- Outlet attachment type: Threaded
- Inlet diameter: 0.568 in
- Shaft type: Keyed
- Pulley belt type: V-belt
Build and materials
- Housing material: Cast iron
- Condition: New
- Country of origin: China
In the box
One power steering pump, a sealing kit and an instruction sheet. The pulley, reservoir, reservoir cap, filter and mounting hardware are not included, so plan on new bolts.
Interchange: 4432035220 · 4432035270 · 4432035351 · 4432035370 · 4432035380 · 4432035410 · 4432035411 · 4432035430
Product information is for general reference and may contain errors. See our Disclaimer.
This part cross-references / interchanges with the following part numbers:
4432035220, 4432035270, 4432035351, 4432035370, 4432035380, 4432035410, 4432035411, 4432035430
Frequently Asked Questions
Is this the power steering pump replacement for a 1988-1995 Toyota 4Runner?
Yes. CARDONE 96-5844 fits the 1988-1995 Toyota 4Runner and the 1988-1995 Toyota Pickup, and each of them takes one pump.
What comes with the CARDONE power steering pump?
CARDONE 96-5844 comes with the pump, a sealing kit and an instruction sheet. The pulley, reservoir, reservoir cap, filter and mounting hardware are not included.
Does the CARDONE steering pump use a barb or an O-ring fitting?
Both appear on this pump: a barb inlet, a threaded 16x1.5 outlet and an O-ring hose port. The inlet diameter is 0.568 in.
Why do I only get steering assist at higher engine rpm after installing a replacement pump?
Debris in the flow control valve bore can keep the valve from moving as it should. The valve and bore sit behind the high-pressure fitting, and the system must be checked for contamination and flushed.
What if my old pulley fits loosely on the new pump shaft?
A pulley that cracked on removal, or whose bore a mushroomed shaft enlarged, must be replaced, and CARDONE 96-5844 does not include a pulley.
