CARDONE Reman Power Steering Pump P/N:20-54500
A1 CARDONE 20-814 power steering pump for the 2002-2005 Jeep Liberty is a remanufactured pump that supplies the hydraulic pressure behind steering assist.
A whine, heavy steering or fluid seepage at the pump can mean it is worn, though the hoses, the belt and the steering gear can produce those symptoms too. With the engine off, look over the pump, hoses and belt for leaks, cracks or a loose pulley before you buy a pump.
This A1 CARDONE power steering pump is a direct-fit replacement for the 2002-2005 Jeep Liberty. The 2002-2005 Jeep Liberty takes one pump, and this listing is one.
Fit and size
Build and materials
One power steering pump, one instruction sheet and one sealing kit. The pulley, reservoir, reservoir cap, filter and mounting hardware are not included, so plan on new mounting bolts rather than reusing the old ones.
Interchange: 52088711AA · 52088711AB · 52088711AC · 52088711AD · 52088711AE
Product information is for general reference and may contain errors. See our Disclaimer.
This part cross-references / interchanges with the following part numbers:
Is the A1 CARDONE 20-814 a power steering pump replacement for a 2004 Jeep Liberty?
Yes. A1 CARDONE 20-814 fits the 2002-2005 Jeep Liberty, and 2004 falls inside that range. The 2002-2005 Jeep Liberty takes one pump.
Yes. A1 CARDONE 20-814 fits the 2002-2005 Jeep Liberty, and 2004 falls inside that range. The 2002-2005 Jeep Liberty takes one pump.
Does the A1 CARDONE 20-814 come with a pulley or reservoir?
No. The pump comes with an instruction sheet and a sealing kit. The pulley, reservoir, reservoir cap and mounting hardware are not included.
No. The pump comes with an instruction sheet and a sealing kit. The pulley, reservoir, reservoir cap and mounting hardware are not included.
Does the A1 CARDONE 20-814 come with a pulley or reservoir?
No. The pump comes with an instruction sheet and a sealing kit. The pulley, reservoir, reservoir cap and mounting hardware are not included.
No. The pump comes with an instruction sheet and a sealing kit. The pulley, reservoir, reservoir cap and mounting hardware are not included.
What size are the inlet and outlet on this power steering pump?
The inlet is a barb, 20.62 mm (0.812 in) in diameter. The outlet is threaded at 16x1.5, and the hose port type is O-ring.
The inlet is a barb, 20.62 mm (0.812 in) in diameter. The outlet is threaded at 16x1.5, and the hose port type is O-ring.
What size are the inlet and outlet on this power steering pump?
The inlet is a barb, 20.62 mm (0.812 in) in diameter. The outlet is threaded at 16x1.5, and the hose port type is O-ring.
The inlet is a barb, 20.62 mm (0.812 in) in diameter. The outlet is threaded at 16x1.5, and the hose port type is O-ring.
Why would a power steering pump whine or steer hard?
A worn pump can whine or make steering heavy, and low fluid or a loose belt can do the same. A shop can test pressure and flow to find out which.
A worn pump can whine or make steering heavy, and low fluid or a loose belt can do the same. A shop can test pressure and flow to find out which.
Why would a power steering pump whine or steer hard?
A worn pump can whine or make steering heavy, and low fluid or a loose belt can do the same. A shop can test pressure and flow to find out which.
A worn pump can whine or make steering heavy, and low fluid or a loose belt can do the same. A shop can test pressure and flow to find out which.
How is this remanufactured pump tested before it ships?
Every A1 CARDONE 20-814 gets a hydraulic efficiency test. The final assembly is computer-tested for pressure, bypass, fluid flow, valve operation, steering effort and noise.
Every A1 CARDONE 20-814 gets a hydraulic efficiency test. The final assembly is computer-tested for pressure, bypass, fluid flow, valve operation, steering effort and noise.
How is this remanufactured pump tested before it ships?
Every A1 CARDONE 20-814 gets a hydraulic efficiency test. The final assembly is computer-tested for pressure, bypass, fluid flow, valve operation, steering effort and noise.
Every A1 CARDONE 20-814 gets a hydraulic efficiency test. The final assembly is computer-tested for pressure, bypass, fluid flow, valve operation, steering effort and noise.
Is the A1 CARDONE 20-814 a power steering pump replacement for a 2004 Jeep Liberty?
Yes. A1 CARDONE 20-814 fits the 2002-2005 Jeep Liberty, and 2004 falls inside that range. The 2002-2005 Jeep Liberty takes one pump.
Yes. A1 CARDONE 20-814 fits the 2002-2005 Jeep Liberty, and 2004 falls inside that range. The 2002-2005 Jeep Liberty takes one pump.
Does the A1 CARDONE 20-814 come with a pulley or reservoir?
No. The pump comes with an instruction sheet and a sealing kit. The pulley, reservoir, reservoir cap and mounting hardware are not included.
No. The pump comes with an instruction sheet and a sealing kit. The pulley, reservoir, reservoir cap and mounting hardware are not included.
Does the A1 CARDONE 20-814 come with a pulley or reservoir?
No. The pump comes with an instruction sheet and a sealing kit. The pulley, reservoir, reservoir cap and mounting hardware are not included.
No. The pump comes with an instruction sheet and a sealing kit. The pulley, reservoir, reservoir cap and mounting hardware are not included.
What size are the inlet and outlet on this power steering pump?
The inlet is a barb, 20.62 mm (0.812 in) in diameter. The outlet is threaded at 16x1.5, and the hose port type is O-ring.
The inlet is a barb, 20.62 mm (0.812 in) in diameter. The outlet is threaded at 16x1.5, and the hose port type is O-ring.
What size are the inlet and outlet on this power steering pump?
The inlet is a barb, 20.62 mm (0.812 in) in diameter. The outlet is threaded at 16x1.5, and the hose port type is O-ring.
The inlet is a barb, 20.62 mm (0.812 in) in diameter. The outlet is threaded at 16x1.5, and the hose port type is O-ring.
Why would a power steering pump whine or steer hard?
A worn pump can whine or make steering heavy, and low fluid or a loose belt can do the same. A shop can test pressure and flow to find out which.
A worn pump can whine or make steering heavy, and low fluid or a loose belt can do the same. A shop can test pressure and flow to find out which.
Why would a power steering pump whine or steer hard?
A worn pump can whine or make steering heavy, and low fluid or a loose belt can do the same. A shop can test pressure and flow to find out which.
A worn pump can whine or make steering heavy, and low fluid or a loose belt can do the same. A shop can test pressure and flow to find out which.
How is this remanufactured pump tested before it ships?
Every A1 CARDONE 20-814 gets a hydraulic efficiency test. The final assembly is computer-tested for pressure, bypass, fluid flow, valve operation, steering effort and noise.
Every A1 CARDONE 20-814 gets a hydraulic efficiency test. The final assembly is computer-tested for pressure, bypass, fluid flow, valve operation, steering effort and noise.
How is this remanufactured pump tested before it ships?
Every A1 CARDONE 20-814 gets a hydraulic efficiency test. The final assembly is computer-tested for pressure, bypass, fluid flow, valve operation, steering effort and noise.
Every A1 CARDONE 20-814 gets a hydraulic efficiency test. The final assembly is computer-tested for pressure, bypass, fluid flow, valve operation, steering effort and noise.
