Rear Brake Drum for 2000-2005 Workhorse P30 & More - Centric Parts 122.66029

$166.99

Vehicles this part fits

    Part number: 122.66029
    UPC: 805890045854
    Condition: New
    Weight: 55.00 LBS
    Item Package Quantity: 1
    $166.99
    Adding to cart… The item has been added

    Have questions?

    Centric Parts Brake Drum P/N:122.66029
    Centric Parts Brake Drum P/N:122.66029
    $166.99
    $166.99

    Centric Parts 122.66029 rear brake drum for the 2000-2005 Workhorse P30 and other vehicles gives the brake shoes a friction surface to press against when you brake. This Centric Parts brake drum is OE-matched in fit, form and function.

    • Centric Premium line, built to SAE international standard material for structural integrity
    • Precision machined friction surfaces for smooth operation and reduced noise
    • 100% mill balanced for vibration-free performance
    • Black painted exterior for corrosion resistance
    • Outer cooling fins on the drum
    • Machined finishes for a cleaner appearance through the wheels

    Quick facts

    • Part: Centric Parts 122.66029 brake drum
    • Fits: the 2000-2005 Workhorse P30 and other vehicles
    • Position: Rear
    • Condition: New

    Noise or vibration under braking, or deep grooves and cracks in the friction surface, can mean a drum is worn. Before replacing one, find out what is causing the noise or vibration; during a brake service, look over the friction surface and measure the inside diameter against the discard diameter below. If the drum is the cause, this one replaces it.

    Fits

    This rear brake drum fits the 2000-2005 Workhorse P30, the 1999-2005 Workhorse P32 and the 1999-2005 Workhorse P42, along with many other vehicles. Driving something else? Look up your own year and model in the "Vehicles it fits" section.

    Specifications

    Fit and size

    • Position: Rear
    • Quantity per vehicle: 2
    • Nominal drum diameter: 330.200 mm (13.000 in)
    • Maximum discard diameter: 332.500 mm (13.090 in)
    • Outside diameter: 411.480 mm (16.200 in)
    • Bolt circle diameter: 165.100 mm (6.500 in), 8 bolt holes
    • Mounting hole diameter: 15.750 mm (0.620 in)
    • Hub hole / register: 116.840 mm (4.600 in)
    • Friction surface width: 102.108 mm (4.020 in)

    Build and materials

    • Mounting type: Floating
    • Outer cooling fins: Yes
    • Exterior: black painted
    • Balance: 100% mill balanced
    • Condition: New
    • Country of origin: China

    In the box

    One brake drum. This listing is one drum, the vehicle takes two, and both sides are normally replaced together.

    Product information is for general reference and may contain errors. See our Disclaimer.

    Frequently Asked Questions

    Does the Centric Parts 122.66029 fit the 1999-2005 Workhorse P32?

    Yes. Centric Parts 122.66029 is a rear brake drum that fits the 1999-2005 Workhorse P32. For another vehicle, look in the "Vehicles it fits" section.

    What is the discard diameter of the Centric Parts 122.66029 brake drum?

    Centric Parts 122.66029 has a nominal drum diameter of 330.200 mm (13.000 in) and a maximum discard diameter of 332.500 mm (13.090 in).

    What is the bolt circle on this rear brake drum?

    The bolt circle is 165.100 mm (6.500 in) with 8 bolt holes. The mounting hole diameter is 15.750 mm (0.620 in) and the hub hole is 116.840 mm (4.600 in).

    Does this brake drum have a rust-resistant finish?

    Yes. The exterior has a black painted coating for corrosion resistance, and the drum has outer cooling fins.

    What signs can mean a rear brake drum is worn?

    Vibration or noise when braking, or deep grooves and cracks in the friction surface, can mean wear. A shop can measure the drum against the 332.500 mm discard diameter.
