Front Right CV Axle Shaft for 2020-2022 Toyota Corolla & More - TrakMotive TO-8435

$211.99

Vehicles this part fits

    Part number: TO-8435
    UPC: 844084049759
    Condition: New
    Weight: 19.20 LBS
    Item Package Quantity: 1
    $211.99
    Adding to cart… The item has been added

    Have questions?

    TrakMotive CV Axle Shaft P/N:TO-8435
    TrakMotive CV Axle Shaft P/N:TO-8435
    $211.99
    $211.99

    TrakMotive TO-8435 front right CV axle shaft for the 2020-2022 Toyota Corolla and other vehicles sends drive torque to the wheel and flexes with suspension movement.

    • Male inboard joint with a 24-spline connection
    • Conventional outboard joint with a 26-spline connection
    • Neoprene boots on the inboard and outboard joints
    • Axle nut included, with stake-style locking

    Quick facts

    • Part: TrakMotive TO-8435 CV axle shaft
    • Fits: 2020-2022 Toyota Corolla and other vehicles
    • Position: Front right
    • Condition: New

    A torn boot with grease thrown around it, clicking in turns or vibration under acceleration can mean a CV axle is worn. Before you replace this axle, rule out the wheel bearing, tires and brakes, which can produce noise or vibration too.

    Fits

    It fits the 2020-2022 Toyota Corolla, the 2016-2021 Toyota Prius and the 2017-2019 Toyota Prius Prime; the front right takes one axle. This listing is one axle, the front left is a separate part, and both sides are normally replaced together.

    Specifications

    Fit and size

    • Position: Front right
    • Quantity per application: 1
    • Overall compressed length: 950 mm (37.38 in)
    • Inboard splines: 24
    • Outboard splines: 26
    • Axle nut thread size: M22x1.5
    • Axle nut hex size: 30 mm (1.18 in)

    Build and materials

    • Inboard joint: male, spline shaft connection
    • Outboard joint: conventional, spline shaft connection
    • Inboard and outboard joint boots: neoprene
    • Axle nut locking type: stake
    • ABS tone ring: not included
    • Condition: New
    • Warranty: TrakMotive limited lifetime warranty
    • Country of origin: China

    In the box

    One front right CV axle shaft with its axle nut. The ABS tone ring is not included.

    Interchange: 66-5449
    NCV19001K · NCV69192 · 4341047040

    Product information is for general reference and may contain errors. See our Disclaimer.

    This part cross-references / interchanges with the following part numbers:

    66-5449, NCV19001K, NCV69192, 4341047040, TO-8435

    Frequently Asked Questions

    Does the TrakMotive TO-8435 fit the 2016-2021 Toyota Prius?

    Yes. TrakMotive TO-8435 is a front right CV axle shaft for the 2016-2021 Toyota Prius. It is sold one per listing, so the front left side is ordered separately.

    Does the TrakMotive CV axle come with the axle nut?

    Yes. The axle nut is included, with an M22x1.5 thread, a 30 mm hex and stake-style locking. The ABS tone ring is not included.

    How many splines are on the TrakMotive CV axle shaft?

    The male inboard joint has 24 splines and the conventional outboard joint has 26. Overall compressed length is 950 mm (37.38 in).

    Does a clicking noise in turns mean the front right CV axle is worn?

    It can. A click when turning, a torn boot or vibration under power are common signs of a worn axle. Have a shop inspect it promptly instead of driving on it.

    Does TrakMotive TO-8435 replace interchange number 4341047040?

    Yes. Number 4341047040 is on the interchange list for TrakMotive TO-8435, along with 66-5449, NCV19001K and NCV69192.
