TrakMotive TO-8334 front left CV axle shaft for the 2013-2018 Toyota RAV4 and other vehicles sends drive torque to the wheel. Its inboard and outboard joints let the wheel turn and move with the suspension.
- Neoprene boots on both the inboard and outboard joints
- Male inboard joint with 24 splines
- Conventional outboard joint with 30 splines
- Axle nut locks in place by staking
Quick facts
- Part: TrakMotive TO-8334 CV axle shaft
- Fits: 2013-2018 Toyota RAV4 and other vehicles
- Position: Front left
- Condition: New
A clicking noise in turns, vibration while driving or a torn boot with grease thrown around it can mean the axle is worn. A worn wheel bearing, a worn ball joint or an out-of-balance tire can be behind similar signs, so find the cause before buying an axle.
Fits
This CV axle shaft is a direct-fit replacement for the 2013-2018 Toyota RAV4 and the 2011-2016 Scion tC.
Specifications
Fit and size
- Position: front left
- Quantity per vehicle: 1
- Overall compressed length: 643 mm (25.31 in)
- Axle nut thread size: M22x1.5
- Axle nut hex size: 30 mm
- Axle nut height: 22 mm, length: 35 mm
Build and materials
- Condition: new
- ABS tone ring: not included
- Warranty: TrakMotive limited lifetime warranty
- Country of origin: China
In the box
One front left CV axle shaft with its axle nut. This listing holds one axle, and the front left takes one; the front right is a separate part, ordered separately.
Interchange: 66-5444 · TO-8-8833
329334 · NCV69069 · NCV69069XD · 90851 · 434200R080 · 434200R081 · 434200R082 · 4342028090 · TO10584ER
Product information is for general reference and may contain errors. See our Disclaimer.
This part cross-references / interchanges with the following part numbers:
329334, 66-5444, NCV69069, NCV69069XD, 90851, TO-8-8833, 434200R080, 434200R081, 434200R082, 4342028090, TO10584ER, TO-8334
Frequently Asked Questions
Will the TrakMotive TO-8334 fit a 2013-2018 Toyota RAV4?
Yes. TrakMotive TO-8334 is a front left CV axle shaft for the 2013-2018 Toyota RAV4, and it also fits the 2011-2016 Scion tC.
Does the TrakMotive CV axle come with the axle nut?
Yes. The axle nut is included. It has an M22x1.5 thread and a 30 mm hex, and it locks by staking.
How many splines does the TrakMotive CV axle shaft have?
TrakMotive TO-8334 has 24 splines on its male inboard joint and 30 splines on its conventional outboard joint.
How can I tell if a front left CV axle is worn?
A split or torn boot with grease thrown around it shows up on a visual look with the engine off. Clicking in turns or vibration while driving can also be signs of wear.
Does this front left CV axle include an ABS tone ring?
No. The ABS tone ring is not included with this axle.
