Dorman 697-500 rear drive shaft pinion yoke for the 1999-2006 Chevrolet Silverado 1500 and other vehicles connects the driveshaft to the differential. This Dorman drive shaft pinion yoke, also listed as a differential end yoke, matches the fit and construction of the original yoke.
- Machined from cast iron for strength, with precision machining for reliability
- Seal and nut come in the kit
- 30 splines and 4 mounting holes
- Universal joint series 3R
- Inside diameter of 33.2 mm
Quick facts
- Part: Dorman 697-500 drive shaft pinion yoke
- Fits: 1999-2006 Chevrolet Silverado 1500 and other vehicles
- Position: Rear differential
- Material: Cast iron
- Condition: New
Driveline vibration or play where the driveshaft meets the differential can mean the pinion yoke is worn, though a worn universal joint or an unbalanced driveshaft can be behind it too, so rule those out first.
Fits
The 1999-2006 Chevrolet Silverado 1500, the 1995-2008 Chevrolet Tahoe and the 1999-2006 GMC Sierra 1500 take one pinion yoke each at the rear differential, and so do many other Chevrolet, GMC, Buick, Cadillac, Oldsmobile and Pontiac models. If your truck or car is not named here, look up its model and year in the "Vehicles it fits" section. Fit was validated by testing.
Specifications
Fit and size
- Position: rear differential
- Quantity per vehicle: 1
- Inside diameter: 33.2 mm
- Mounting hole diameter: 7 mm, 4 mounting holes
- Length: 102 mm
- Width: 65.6 mm
- Spline quantity: 30
- Universal joint series: 3R
Build and materials
- Type: pinion yoke kit with seal and nut
- Material: cast iron
- Condition: new
- Country of origin: India
In the box
One drive shaft pinion yoke with seal and nut. U-bolts, universal joints and mounting hardware are not included; plan on new U-bolts and mounting hardware, as the old ones may not be reusable.
Interchange: 12470387
Frequently Asked Questions
Is the Dorman 697-500 pinion yoke right for a 1999-2006 Chevrolet Silverado 1500?
Yes. Dorman 697-500 fits the 1999-2006 Chevrolet Silverado 1500 as a rear differential yoke, one per vehicle. If your vehicle is a different model, look it up in the "Vehicles it fits" section.
Does this pinion yoke come with a seal and nut?
Yes. The kit includes the seal and nut. U-bolts, universal joints and mounting hardware are not included and are bought separately.
How many splines does the Dorman 697-500 pinion yoke have?
Dorman 697-500 has 30 splines, a 33.2 mm inside diameter and four 7 mm mounting holes. It is for universal joint series 3R.
Is this pinion yoke made of cast iron?
Yes. The yoke is cast iron, machined for strength and precision machined for reliability.
Does the Dorman 697-500 pinion yoke interchange with 12470387?
Yes. 12470387 is listed as an interchange number for Dorman 697-500.
