Coolant Pipe for 2001-2025 Chevrolet Silverado 2500 HD & More - Dorman 626-661

$83.99

Vehicles this part fits

    Part number: 626-661
    UPC: 889245321992
    Condition: New
    Weight: 4.02 LBS
    Item Package Quantity: 1
    $83.99
    Adding to cart… The item has been added

    Have questions?

    Dorman - OE Solutions Engine Coolant Pipe P/N:626-661
    Dorman - OE Solutions Engine Coolant Pipe P/N:626-661
    $83.99
    $83.99

    Dorman 626-661 coolant pipe for the 2001-2025 Chevrolet Silverado 2500 HD V8 6.6L and other vehicles carries coolant from the water pump to the engine oil cooler. This engine coolant pipe is a direct replacement for the original pipe.

    • Engineered to help keep coolant transfer leak-free when an original pipe has failed from heat or corrosion
    • Steel tube with a black epoxy finish
    • Flange connection at one end and an O-ring connection at the other
    • Branched coolant hose type with a mounting bracket included
    • Maximum working pressure of 50 psi

    Quick facts

    • Part: Dorman 626-661 coolant pipe
    • Also called: engine coolant pipe
    • Fits: 2001-2025 Chevrolet Silverado 2500 HD V8 6.6L and other vehicles
    • Position: Water pump to engine oil cooler
    • Material: Steel
    • Condition: New

    Coolant drips or stains near the pipe, rust on it, or a falling coolant level can mean the pipe has corroded or cracked. A leaking water pump or engine oil cooler can produce the same leak, so find the source before replacing anything. Look only with the engine off and cool.

    Fits

    The 2001-2025 Chevrolet Silverado 2500 HD V8 6.6L, the 2007-2025 Chevrolet Silverado 3500 HD V8 6.6L and the 2019-2025 Chevrolet Silverado 4500 HD V8 6.6L all fit this pipe, along with many other vehicles. A 2007-2025 Chevrolet Silverado 3500 HD V8 6.6L takes one, and this listing is a single pipe.

    Specifications

    Fit and size

    • Position: water pump to engine oil cooler
    • Quantity per vehicle: 1
    • Length: 16.3 in
    • Inside diameter: 1.65 in at end 1, 1.61 in at end 2
    • Outside diameter: 2.1 in
    • Hose end 1 outside diameter: 3.46 in
    • Hose end 2 outside diameter: 1.93 in
    • Mounting bracket hole diameter: 6 mm

    Build and materials

    • Material: steel
    • Finish: black epoxy
    • End 1 type: flange
    • End 2 type: O-ring
    • Coolant hose type: branched
    • Maximum working pressure: 50 psi
    • Condition: new
    • Country of origin: China

    In the box

    One coolant pipe assembly, one gasket, one O-ring and a mounting bracket. A heat shield and a protective sleeve are not included.

    Interchange: 12636733 · 12725092 · 97352450

    Product information is for general reference and may contain errors. See our Disclaimer.

    This part cross-references / interchanges with the following part numbers:

    12636733, 12725092, 97352450

    Frequently Asked Questions

    Does the Dorman 626-661 coolant pipe fit a 2019-2025 Chevrolet Silverado 4500 HD V8 6.6L?

    Yes. Dorman 626-661 fits the 2019-2025 Chevrolet Silverado 4500 HD V8 6.6L, along with many other vehicles. To check your own vehicle, look in the "Vehicles it fits" section.

    What comes with the Dorman 626-661 coolant pipe besides the tube?

    Dorman 626-661 comes with the pipe assembly, one gasket, one O-ring and a mounting bracket. A heat shield and a protective sleeve are not included.

    What pressure is this steel coolant pipe rated for?

    This coolant pipe has a maximum working pressure of 50 psi. It is a steel tube with a black epoxy finish, 16.3 in long.

    How can I tell if the coolant pipe between the water pump and oil cooler is failing?

    With the engine off and cool, look for coolant drips, stains or rust on the pipe. A falling coolant level is another sign, and a shop can pressure-test the system.

    Does Dorman 626-661 replace number 12636733?

    Yes. 12636733 is one of the numbers Dorman 626-661 replaces, and it appears on the Interchange line.
