Dorman 523-052 rear lower lateral arm for the 2005-2009 Buick LaCrosse and other vehicles locates the rear wheel in the suspension through a bushing at each end. This Dorman lateral arm is a standard replacement grade that bolts on.
- Part of the Dorman OE Solutions line
- Tubular steel arm with a straight shape, 673.5 mm long
- Rubber bushings included at both ends, which saves time and labor where they apply
- Corrosion-resistant construction
- Tested by product and quality engineers and inspected for quality
Quick facts
- Part: Dorman 523-052 lateral arm
- Fits: 2005-2009 Buick LaCrosse and other vehicles
- Position: Rear left lower forward, rear right lower forward
- Material: Steel
- Condition: New
Worn bushings or a bent arm can show up as a clunk over bumps, uneven rear tire wear or a rear end that feels loose in turns. Before you replace this arm, rule out a worn rear shock or a loose wheel bearing that could make a similar noise. The car has one arm on each side of the rear suspension; this listing is one arm, so order the second for the other side and fit the two together.
Fits
This lateral arm is a direct replacement for the 2005-2009 Buick LaCrosse and the 2005-2009 Buick Allure.
Specifications
Fit and size
- Position: rear left lower forward, rear right lower forward
- Length: 673.5 mm
- Height: 38.5 mm
- Mounting hole diameter: 14 mm
- Mounting holes: 2
- Bushing length: 32 mm and 38.5 mm
Build and materials
- Type: tubular lateral arm, straight shape
- Material: steel
- Bushing material: rubber
- Attachment: bolt-on, with a bushing at each end
- Grade: standard replacement
- Condition: new
- Country of origin: China
In the box
One lateral arm with its rubber bushings. Mounting hardware, a ball joint and a grease fitting are not included; plan on new bolts, since the old ones may not be reusable.
Interchange: CA2602 · 10319451 · 15236247 · RK660275
Product information is for general reference and may contain errors. See our Disclaimer.
This part cross-references / interchanges with the following part numbers:
CA2602, 10319451, 15236247, RK660275
Frequently Asked Questions
Will the Dorman 523-052 lateral arm work on a 2005-2009 Buick Allure?
Yes. Dorman 523-052 is a direct replacement for the 2005-2009 Buick Allure, in the rear lower forward position on the left or right side.
Does this lateral arm include its bushings?
Yes. The arm comes with rubber bushings at both ends. Mounting hardware, a ball joint and a grease fitting are not included.
What are the material and size of this lateral arm?
Dorman 523-052 is a tubular steel arm, 673.5 mm long and 38.5 mm high, with two 14 mm mounting holes and rubber bushings.
Is a clunk over bumps a sign my rear lateral arm is worn?
It can be, since a worn bushing may clunk over bumps, but a shock or wheel bearing can make a similar noise. A shop can check the arm and bushings for play.
Is 15236247 an interchange number for Dorman 523-052?
Yes. 15236247 is listed as an interchange number for this Dorman 523-052 lateral arm.
