Front Right Suspension Strut Assembly for 2016-2022 Chevrolet Camaro - Dorman 949-838

$565.99

Vehicles this part fits

    Part number: 949-838
    UPC: 194883335899
    Condition: New
    Weight: 21.42 LBS
    Item Package Quantity: 1
    $565.99
    Adding to cart… The item has been added

    Have questions?

    Dorman - OE Solutions Suspension Strut Assembly P/N:949-838
    Dorman - OE Solutions Suspension Strut Assembly P/N:949-838
    $565.99
    $565.99

    Dorman 949-838 front right suspension strut assembly for the 2016-2022 Chevrolet Camaro absorbs road impacts and supports the vehicle at the front right corner. It is a magnetic ride control shock built as a direct-fit replacement.

    • Magnetic ride control with electronic damping adjustment
    • Adjustable compression and rebound damping
    • Single-tube body with progressive valving
    • Strut mount and bump stop included
    • Tested in the laboratory, for durability and on the vehicle

    Quick facts

    • Part: Dorman 949-838 suspension strut assembly
    • Fits: 2016-2022 Chevrolet Camaro
    • Position: Front right
    • Material: Steel
    • Condition: New

    A bouncy ride, a fluid leak on the strut body or a clunk over bumps can mean a strut is worn. These signs alone do not prove this strut is the problem, since a worn tire can cause similar vibration. This listing is one strut, and both front sides are normally replaced together.

    Fits

    It fits the 2016-2022 Chevrolet Camaro.

    Specifications

    Fit and size

    • Position: front right
    • Quantity per vehicle: 1 for the front right
    • Body and cylinder outside diameter: 40 mm
    • Rod diameter: 14 mm
    • Travel length: 125 mm
    • Body, extended and compressed length: 591.2 mm

    Build and materials

    • Construction: single tube
    • Damping adjustment: electronic
    • Housing, shaft and cylinder material: steel
    • Cylinder finish: painted
    • Condition: new
    • Country of origin: China

    In the box

    One magnetic ride control shock with its strut mount and bump stop. The front right takes one, and the front left is a separate part. The coil spring, mounting hardware, bushing, boot, dust shield, strut mount insulators and sway bar end links are not included, so plan on new bolts, since the old ones may not be reusable.

    Interchange: 84421288 · 84943061

    Product information is for general reference and may contain errors. See our Disclaimer.

    This part cross-references / interchanges with the following part numbers:

    84421288, 84943061

    Frequently Asked Questions

    Is the Dorman 949-838 front right strut the right one for the 2016-2022 Chevrolet Camaro?

    Yes. Dorman 949-838 is the front right strut for the 2016-2022 Chevrolet Camaro. The front left side is a separate part.

    Does this magnetic ride shock come with a strut mount or a coil spring?

    Dorman 949-838 includes the strut mount and a bump stop. The coil spring, mounting hardware, bushing, boot and dust shield are not included.

    Is the damping adjustable on this magnetic ride control strut?

    Yes. This front right strut has electronic damping adjustment with adjustable compression and rebound in a single-tube body. The front right takes one; the front left is a separate part.

    How can I tell if a magnetic ride strut is leaking or worn?

    With the vehicle parked and cool, look at the strut body for fluid leaks or a bent rod. A shop can test the electronic damping.

    What are the travel length and rod diameter of Dorman 949-838?

    Travel length is 125 mm and rod diameter is 14 mm. The body and cylinder outside diameter is 40 mm.
