Four Seasons Engine Coolant Thermostat Housing P/N:86110
Four Seasons 86036 lower engine coolant thermostat housing for the 2007-2017 Toyota Camry V6 3.5L and other vehicles houses the thermostat in the engine's coolant flow path.
A coolant leak or crusting at the housing, a crack you can see with the engine cool, or a temperature gauge that climbs can mean the housing needs replacing. A worn thermostat, a tired radiator hose or a weak water pump can show similar signs, so find the cause before buying.
The 2007-2017 Toyota Camry V6 3.5L, 2008-2017 Toyota Highlander V6 3.5L and 2006-2012 Toyota RAV4 V6 3.5L take one housing each, and it fits more vehicles besides. It is a direct-fit replacement that meets and/or exceeds OEM standard.
Fit and size
Build and materials
One thermostat housing. The thermostat and the gasket or seal are not included, so plan on getting them separately.
Interchange: 6053810 · 815856 · 9021086 · 9025861 · 163230P030 · 163230W011 · 1632331040 · CH7036 · W98566
Product information is for general reference and may contain errors. See our Disclaimer.
This part cross-references / interchanges with the following part numbers:
Does the Four Seasons 86036 thermostat housing fit the 2007-2017 Toyota Camry V6 3.5L?
Yes, Four Seasons 86036 fits the 2007-2017 Toyota Camry V6 3.5L, one per vehicle. If your car is a different one, look it up in the "Vehicles it fits" section on this page.
Does this lower thermostat housing come with a thermostat?
No. This Four Seasons 86036 housing is the style without a thermostat, and no gasket or seal is included, so both are bought separately.
What material and port sizes does the 86036 thermostat housing have?
The housing is aluminum, with a 0.747 in inlet diameter, a 0.375 in discharge end and a 2.58 in length.
How can I tell if this thermostat housing is leaking?
With the engine off and cool, look for coolant residue, crusting or a crack around the housing, and watch for coolant loss or a rising temperature gauge. A shop can pressure-test the cooling system.
Does Four Seasons 86036 replace number 163230W011?
Yes, 163230W011 is one of the numbers Four Seasons 86036 replaces, along with 163230P030 and 1632331040.
