Dorman 03428 exhaust manifold nut for the 2011-2015 Chevrolet Cruze 4-cylinder 1.4L and other vehicles holds the exhaust manifold in place on the engine. This Dorman exhaust manifold nut replaces a nut that is missing or has given out from fatigue.
- Heat-hardened brass construction
- Locking nut with a shouldered end and a ball seat
- Fine metric thread with a 1.25 mm pitch, turning clockwise
- 10 mm hex size and 6.8 mm inside diameter
- No washer attached to the nut
Quick facts
- Part: Dorman 03428 exhaust manifold nut
- Fits: the 2011-2015 Chevrolet Cruze 4-cylinder 1.4L and other vehicles
- Material: Brass
- Condition: New
A ticking sound at a cold start, an exhaust smell, or a stripped or missing nut can mean this nut has worn out, though a leaking exhaust manifold gasket or a cracked manifold can be behind the same symptoms, so find the cause before replacing it.
Fits
The 2011-2015 Chevrolet Cruze 4-cylinder 1.4L, the 2013-2019 Chevrolet Trax 4-cylinder 1.4L and the 2013-2019 Buick Encore 4-cylinder 1.4L are cars this exhaust manifold nut fits, and it is a direct-fit replacement for them and other vehicles. The 2013-2019 Chevrolet Trax 4-cylinder 1.4L takes one nut.
Specifications
Fit and size
- Quantity per vehicle: 1
- Pieces in the pack: 8
- Inside diameter: 6.8 mm
- Hex size: 10 mm
- Height: 22 mm
- Depth: 16 mm
- Thread: metric, fine, 1.25 mm pitch, clockwise
Build and materials
- Type: hex nut
- Material and finish: brass
- Heat hardened: yes
- Locking: yes, with a shouldered end
- Seat type: ball
- Washer: not attached
- Condition: new
- Country of origin: China
In the box
Eight exhaust manifold nuts.
Interchange: 55565352
Product information is for general reference and may contain errors. See our Disclaimer.
Frequently Asked Questions
Are these Chevy Cruze exhaust manifold nuts right for the 2011-2015 model with the 4-cylinder 1.4L?
Yes, Dorman 03428 fits the 2011-2015 Chevrolet Cruze 4-cylinder 1.4L and the 2013-2019 Chevrolet Trax 4-cylinder 1.4L; for any other car, look it up in the "Vehicles it fits" section.
How many nuts come in the Dorman 03428 pack, and is a washer attached?
Eight exhaust manifold nuts come in the Dorman 03428 pack. No washer is attached to the nut.
What hex size and thread do these brass exhaust manifold nuts have?
The hex size is 10 mm. The thread is metric, fine and clockwise with a 1.25 mm pitch, and the inside diameter is 6.8 mm.
How can I tell if an exhaust manifold nut is loose or failing?
With the engine off and cool, look for a stripped, rusted or missing nut at the manifold. A ticking noise at a cold start can also go with an exhaust leak, which a shop can trace.
Is this exhaust manifold nut heat hardened and locking?
Yes. This exhaust manifold nut is heat hardened and locking, with a shouldered end and a ball seat.
