Right Cylinder Head Gasket for 2005-2010 Chrysler 300 & More - FEL-PRO 9517 PT

$56.99

Vehicles this part fits

    Part number: 9517PT
    UPC: 614046622821
    Condition: New
    Weight: 1.10 LBS
    Item Package Code: EA
    Part Has Core (Y/N): N
    Item Package Quantity: 1
    $56.99
    Adding to cart… The item has been added

    Have questions?

    FEL-PRO Engine Cylinder Head Gasket P/N:9517 PT
    FEL-PRO Engine Cylinder Head Gasket P/N:9517 PT
    $56.99
    $56.99

    FEL-PRO 9517 PT right cylinder head gasket for the 2005-2010 Chrysler 300 V6 2.7L and other vehicles seals the joint between the cylinder head and the engine block. This FEL-PRO cylinder head gasket is designed for imperfect sealing surfaces in the repair environment.

    • PermaTorque multi-layered construction maintains sealing stress and accommodates head lift
    • Proprietary coating helps withstand rougher sealing surface finishes up to 80 Ra
    • Precise embossed sealing beads at all vital areas to eliminate leak paths
    • Unique combustion seal accommodates high cylinder pressures and head movement

    Quick facts

    • Part: FEL-PRO 9517 PT cylinder head gasket
    • Also called: engine cylinder head gasket
    • Fits: 2005-2010 Chrysler 300 V6 2.7L and other vehicles
    • Position: Right
    • Material: PermaTorque MLS
    • Condition: New

    Coolant loss, overheating or white exhaust smoke can mean the cylinder head gasket has failed. A cracked cylinder head, a warped sealing surface or a leaking coolant hose can produce similar symptoms, so find the cause before you buy. This listing is one right-side gasket; the left side is a separate part, and both sides are normally replaced together.

    Fits

    The vehicles it fits include the 2005-2010 Chrysler 300 V6 2.7L, the 2006-2010 Dodge Charger V6 2.7L and the 2008-2010 Dodge Avenger V6 2.7L.

    Specifications

    Fit and size

    • Position: Right
    • Quantity per vehicle: 1
    • Thickness: 1.493 mm
    • Cylinder bore diameter: 3.480 in (88.38 mm)
    • Head gasket bore: 3.479 in (88.62 mm)

    Build and materials

    • Material: PermaTorque MLS
    • Coating: proprietary coating
    • Gasket sealant: not included
    • Condition: New
    • Country of origin: United States

    In the box

    One right cylinder head gasket; the right side takes one. Gasket sealant is not included.

    Interchange: AHG235L · 4663694AC · 4792932AA · 4792932AC · 20872 · 20873 · 54231 · 611003500 · 611036900

    Product information is for general reference and may contain errors. See our Disclaimer.

    This part cross-references / interchanges with the following part numbers:

    AHG235L, 4663694AC, 4792932AA, 4792932AC, 20872, 20873, 54231, 611003500, 611036900

    Frequently Asked Questions

    Is this Chrysler 300 cylinder head gasket right for a 2005-2010 model with the V6 2.7L?

    Yes. The FEL-PRO 9517 PT right-side gasket is listed for the 2005-2010 Chrysler 300 V6 2.7L. If your car is a different model, look it up in the "Vehicles it fits" section on this product page.

    Is this Dodge Charger cylinder head gasket right for the 2006-2010 model with the V6 2.7L?

    Yes. The 2006-2010 Dodge Charger V6 2.7L is listed for the right-side FEL-PRO 9517 PT, and it takes one gasket for that side.

    Is sealant included with this engine cylinder head gasket?

    No. Gasket sealant is not included with the FEL-PRO 9517 PT. The listing is one right-side gasket only.

    Are FEL-PRO head gaskets like this PermaTorque MLS one coated?

    Yes. This gasket has a proprietary coating that helps it withstand rougher sealing surface finishes up to 80 Ra.

    How thick is the FEL-PRO 9517 PT cylinder head gasket?

    This cylinder head gasket is 1.493 mm thick. Its cylinder bore diameter is 3.480 in (88.38 mm).
