Gates 38286 belt tensioner for the 1998-2008 Toyota Corolla 4-cylinder 1.8L and other vehicles holds the accessory drive belt at the right tension. This Gates belt tensioner uses the same or improved technology and materials as the original part.
- Part of the Gates DriveAlign automatic belt drive tensioner line
- Patented labyrinth seal protects the internal components
- Patented vibration-damping system absorbs extreme vibration to improve tensioner, belt and accessory life
- Torsional round spring design for reliability and consistent tension
Quick facts
- Part: Gates 38286 belt tensioner
- Also called: serpentine belt tensioner
- Fits: 1998-2008 Toyota Corolla 4-cylinder 1.8L and other vehicles
- Material: Thermoplastic
- Condition: New
Squealing or chirping near the belt, uneven belt wear, or a wobbling, rattling tensioner pulley can come from this part. A worn belt or a failing accessory pulley makes similar noise. With the engine off and cool, look over the belt and the tensioner pulley for cracks, glazing or rubbing marks before you order. The 1998-2008 Toyota Corolla 4-cylinder 1.8L takes one.
Fits
The 1998-2008 Toyota Corolla 4-cylinder 1.8L and the 2003-2008 Pontiac Vibe 4-cylinder 1.8L take this belt tensioner, as does the 2003-2008 Toyota Matrix 4-cylinder 1.8L, along with other vehicles. If your car is not one of these, enter its year, make and model in the "Vehicles it fits" section to see whether this tensioner is listed for it.
Specifications
Fit and size
- Quantity per vehicle: 1
- Outside diameter: 70 mm (2.76 in)
- Bearing bore inside diameter: 17 mm (0.67 in)
- Width: 25 mm (0.98 in)
- Mounting holes: 2
Build and materials
- Material: Thermoplastic
- Belt type: V-ribbed
- Contact surface: smooth, belt backside
- Pulley flanged: No
- Condition: New
- Country of origin: Canada
In the box
One belt tensioner and one hydraulic damper.
Frequently Asked Questions
Is the Gates 38286 a Toyota Corolla belt tensioner for 1998-2008 models with the 4-cylinder 1.8L?
Yes. Gates 38286 is listed for the 1998-2008 Toyota Corolla 4-cylinder 1.8L, and it fits other vehicles too. Look up yours in the "Vehicles it fits" section.
Is this the Matrix belt tensioner for the 2003-2008 Toyota Matrix 4-cylinder 1.8L?
Yes. The 2003-2008 Toyota Matrix 4-cylinder 1.8L is on the fitment list for this Gates belt tensioner, part number 38286.
Does the Gates 38286 come with a hydraulic damper?
Yes. The box holds one belt tensioner and one hydraulic damper.
What are the main dimensions of this Gates belt tensioner?
The outside diameter is 70 mm (2.76 in), the width is 25 mm (0.98 in) and the bearing bore inside diameter is 17 mm (0.67 in). The contact surface is smooth, on the belt backside.
Does this serpentine belt tensioner use a V-ribbed belt?
Yes. The Gates 38286 belt tensioner is listed for a V-ribbed belt, and its pulley contacts the smooth backside of the belt.
