Gates TCKWP321M timing belt kit with water pump for the 1999-2003 Volkswagen Jetta 4-cylinder 1.9L and other vehicles renews the timing belt and water pump together. The water pump is belt-driven and should always be replaced with the timing belt, so this engine timing belt kit with water pump covers the critical parts in one box.
- PowerGrip Timing Component Kit with Water Pump (TCKWP) product line
- Water pump designed and built for efficient cooling
- Trapezoidal-tooth timing belt, 141 teeth, 25 mm wide, HSN with fiberglass cord
Quick facts
- Part: Gates TCKWP321M timing belt kit with water pump
- Also called: engine timing belt kit with water pump
- Fits: 1999-2003 Volkswagen Jetta 4-cylinder 1.9L and other vehicles
- Material: HSN, fiberglass cord (timing belt)
- Condition: New
A cracked or frayed timing belt, a coolant leak at the water pump or a noise from the front of the engine can mean the kit is due. Before you replace it, rule out a leaking hose, radiator or thermostat when the sign is coolant loss or overheating, because problems there can also show up that way.
Fits
It fits the 1999-2003 Volkswagen Jetta 4-cylinder 1.9L, the 1999-2004 Volkswagen Golf 4-cylinder 1.9L and the 1998-2003 Volkswagen Beetle 4-cylinder 1.9L. One kit covers a 1999-2003 Volkswagen Jetta 4-cylinder 1.9L, and the same goes for the other cars named here.
Specifications
Fit and size
- Quantity per vehicle: 1
- Timing belt width: 25 mm (0.984 in)
- Timing belt teeth: 141
- Tooth type: Trapezoidal (I)
- Idlers: 3
Build and materials
- Tensioner type: Spring
- Belt material: HSN, fiberglass cord
- Water pump impeller: metal
- Grade type: OE Performance
- Condition: New
- Warranty: Gates warranty matches the original manufacturer's timing belt replacement intervals, for parts, labor and other associated costs
- Country of origin: Mexico
In the box
One timing belt, one tensioner, three idlers, one water pump with a metal impeller and one O-ring. Bolts, springs and an installation tool are not included; plan on new bolts, as the old ones may not be reusable.
Installation notes
- Detailed installation instructions come with the kit (instruction sheet 0098-1520).
- Technical service bulletins for troublesome applications are included.
Interchange: 3480-0321
PP321LK1MI · PP321LK2MI · TB321LK1MI · GTKWP321 · 24443KM · BWPK41114AM · WPK41114AM
Product information is for general reference and may contain errors. See our Disclaimer.
This part cross-references / interchanges with the following part numbers:
TCKWP321M, PP321LK1MI, PP321LK2MI, TB321LK1MI, 3480-0321, GTKWP321, 24443KM, BWPK41114AM, WPK41114AM
Frequently Asked Questions
Does the Gates TCKWP321M fit a 1999-2004 Volkswagen Golf 4-cylinder 1.9L?
Yes. Gates TCKWP321M fits the 1999-2004 Volkswagen Golf 4-cylinder 1.9L, and that car takes one kit.
Does the Gates timing belt and water pump kit include bolts?
No. Bolts, springs and an installation tool are not included. The kit has a belt, a tensioner, three idlers, a water pump with metal impeller and an O-ring.
How wide is the timing belt in the Gates TCKWP321M, and how many teeth does it have?
The belt is 25 mm (0.984 in) wide with 141 trapezoidal teeth. It is made of HSN with fiberglass cord.
What can show the water pump in a Gates timing belt kit is wearing out?
Coolant seepage around the pump, a whine from the front of the engine or a cracked or frayed belt can mean it is due. Look only with the engine off and cool; a shop can test anything else.
Are installation instructions included with this timing belt kit?
Yes. The Gates TCKWP321M comes with detailed installation instructions (sheet 0098-1520) and technical service bulletins for troublesome applications.
