Gates 24848 radiator coolant hose for the 2016-2018 Western Star 4900SA 6-cylinder 14.0L and other vehicles carries coolant between the radiator, heater and engine. The straight silicone hose is made for extremely high-temperature coolant transfer runs.
- Distinct blue cover
- Silicone tube and cover resist weathering, ozone, heat and coolant deterioration
- Exceeds SAE 20R1 (Class A Standard Wall)
- Temperature range of -70 °F to +350 °F (-56 °C to +177 °C)
Quick facts
- Part: Gates 24848 radiator coolant hose
- Fits: 2016-2018 Western Star 4900SA 6-cylinder 14.0L and other vehicles
- Material: Silicone
- Condition: New
A radiator coolant hose that is cracked, swollen, soft or weeping at the ends can be worn out, though a loose clamp or a leaking radiator can be behind the same coolant loss, so find the source first.
Fits
This hose is listed for a wide range of Freightliner, Kenworth, Peterbilt and Western Star models, including the 2013-2017 Freightliner M2 112 6-cylinder 8.9L, the 2012-2014 Kenworth T800 6-cylinder 12.9L and the 2013-2014 T800 6-cylinder 10.8L, which take one hose each. Open the Buyer's Guide tab to check your exact model and engine.
Specifications
Fit and size
- Quantity per application: 1
- Shape: straight, not molded
- Centerline length: 36 in (914 mm)
- Inside diameter, both ends: 3 in (76 mm)
- Working pressure: 50 psi
Build and materials
- Material: silicone
- Construction: 4-ply
- Cover: blue
- Condition: new
- Country of origin: India
Installation notes
- For a maintenance-free connection, use PowerGrip SB clamps.
- Do not use for fuel or oil transfer applications.
Interchange: KSS-23 · 70-300 · 5515-300 · D9PJ 8333 CA · D9PZ 8333 H
31116 · 3T300 · 78300 · 78300GL · D10298644 · F5061792480125 · 2310994004 · 2310994005 · 57548 · H154825 · 1548 · EH22648
This part cross-references / interchanges with the following part numbers:
31116, 24848, 3T300, 78300, 78300GL, D10298644, F5061792480125, D9PJ 8333 CA, D9PZ 8333 H, 2310994004, 2310994005, 57548, H154825, KSS-23, 1548, 70-300, EH22648, 5515-300
