Oil Pump for 1999-2013 Chevrolet Silverado 1500 & More - MELLING 10295

$197.99

Vehicles this part fits

    Part number: 10295
    UPC: 729295513247
    Condition: New
    Weight: 2.70 LBS
    Item Package Quantity: 1
    $197.99
    Adding to cart… The item has been added

    Have questions?

    HIGH PRESSURE OIL PUMP
    HIGH PRESSURE OIL PUMP
    $197.99
    $197.99

    MELLING 10295 oil pump for the 1999-2013 Chevrolet Silverado 1500 V8 4.8L or 5.3L, the 2003-2006 Silverado 1500 V8 6.0L and other vehicles pumps oil through the engine under pressure. This rotary engine oil pump is driven by the crankshaft, and each one is tested individually for pressure and flow.

    • Takes a 7/8 in. diameter standard bolt-on screen
    • Cast iron cover, CNC machined and phosphate coated
    • Cast aluminum housing, CNC machined and hardcoat anodized
    • Relief valve with a screw-in valve plug and an optional lower stock-pressure spring
    • MELLING high pressure oil pump upgrade for the M295, with 10 PSI more pressure and standard volume
    • Optional +25 psi high pressure spring included for COPO engines

    Quick facts

    • Part: MELLING 10295 oil pump
    • Also called: engine oil pump
    • Fits: the 1999-2013 Chevrolet Silverado 1500 V8 4.8L or 5.3L, the 2003-2006 Silverado 1500 V8 6.0L and other vehicles
    • Material: Cast aluminum housing, cast iron cover, steel rotor
    • Condition: New

    A worn pump can show up as low oil pressure, a pressure warning light or engine noise. Before you replace it, rule out low oil level, a faulty oil pressure sensor and a plugged pickup screen, since they can give similar symptoms.

    Fits

    It is listed for a wide range of Chevrolet, GMC and Cadillac models, including the 1999-2013 GMC Sierra 1500 V8 4.8L or 5.3L, the 2001-2006 Sierra 1500 V8 6.0L, the 2000-2009 Chevrolet Tahoe V8 4.8L and the 2000-2014 Tahoe V8 5.3L. Each engine takes one pump. If your vehicle is not named here, find its year and engine in the "Vehicles it fits" section.

    Specifications

    Fit and size

    • Quantity per vehicle: 1
    • Drive type: Crankshaft
    • Screen: 7/8 in. bolt-on
    • Pickup tube diameter: 0.875 in (22 mm)
    • Inlet size: 0.875 in (22 mm)
    • Mounting holes: 4, each 0.340 in (9 mm) in diameter

    Build and materials

    • Type: Rotary, high pressure, standard volume
    • Pressure: 70 PSI (Red) as made, 10 PSI over the M295
    • Optional springs: 60 PSI (Blue) and 85 PSI (COPO)
    • Adjustable bypass pressure: Yes
    • Housing: Cast aluminum, hardcoat anodized
    • Cover: Cast iron, phosphate coated
    • Rotor material: Steel
    • Condition: New
    • Country of origin: United States

    In the box

    One oil pump with its cover, gasket, o-rings for the screen assembly and alternate pressure springs. The pickup screen, bolts, washers and other hardware are not included, so plan on new bolts.

    Product information is for general reference and may contain errors. See our Disclaimer.

    Frequently Asked Questions

    Is this MELLING oil pump for 5.3 engines right for the 1999-2013 Chevrolet Silverado 1500 V8 5.3L?

    Yes. MELLING 10295 is listed for the 1999-2013 Chevrolet Silverado 1500 V8 5.3L and takes one pump per engine. For another truck or SUV, find its year and engine in the "Vehicles it fits" section.

    Is the MELLING high volume oil pump the same as this 10295?

    No. MELLING 10295 is a standard volume pump with 0% added volume over stock. What it adds is pressure: 10 PSI more than the M295 it upgrades.

    Which pressure springs come with the MELLING 10295?

    The pump is set to 70 PSI (Red). It also comes with alternate springs: an optional lower 60 PSI (Blue) stock-pressure spring and an optional +25 psi spring (85 PSI) for COPO engines.

    Does the MELLING ls oil pump come with a pickup screen?

    No. The 10295 includes the cover, gasket, o-rings for the screen assembly and alternate springs, but no screen, bolts or hardware. It takes a 7/8 in. diameter bolt-on screen.

    What are the housing and cover of this oil pump made of?

    The 10295 housing is cast aluminum, CNC machined and hardcoat anodized. Its cover is cast iron, CNC machined and phosphate coated, and the rotor is steel.
