Monroe 173026 front left strut assembly for the 2015-2021 Jeep Renegade controls wheel movement and carries the coil spring that sets ride height. This Monroe Quick-Strut is fit checked, ride tested and engineered to restore factory ride performance.
- Application-specific coil spring, mount and strut designs tuned to each vehicle's ride and handling
- Coil spring engineered to restore ride height and support the vehicle's weight
- Reduces body sway, vibration and road harshness before it reaches the passenger cabin
- Upper strut mount helps keep steering precise and limits noise, vibration, harshness and memory steer
- Protective coating resists rust and corrosion and is salt spray tested
Quick facts
- Part: Monroe 173026 strut assembly
- Also called: complete strut and coil spring assembly
- Fits: 2015-2021 Jeep Renegade
- Position: Front left
- Condition: New
Fluid on the strut body, a clunk over bumps or extra body sway can mean a strut is worn, though a loose sway bar link or a worn ball joint can be behind them too. When the strut is the cause, this part, also called a complete strut and coil spring assembly, replaces the strut, spring and upper mount together.
Fits
This Monroe strut assembly is one unit for the front left of the 2015-2021 Jeep Renegade, which takes one on that side. The front right is a separate part ordered on its own, and the two sides are normally replaced together.
Specifications
Fit and size
- Position: Front left
- Quantity per vehicle: 1
- Extended length: 22.52 in (572 mm)
- Compressed length: 14.74 in (374.4 mm)
- Travel length: 7.78 in
- Body length: 14.37 in
Build and materials
- Type: gas-charged, passive strut with coil spring
- Adjustable compression: No
- Adjustable ride height: No
- Condition: New
- Warranty: Monroe Limited Lifetime Warranty and Feel the Difference™ Guarantee
- Country of origin: China
In the box
One front left strut assembly with coil spring, strut mount, coil spring insulators, strut mount insulators and mounting hardware.
Installation notes
- No spring compressor is needed.
- The strut, upper mount and coil spring come already assembled into one unit.
Interchange: 33JP1121
Frequently Asked Questions
Is the Monroe quick strut assembly 173026 the right fit for the 2015-2021 Jeep Renegade?
Yes. Monroe 173026 is the front left strut assembly for the 2015-2021 Jeep Renegade, and the front right is ordered as a separate part.
What parts come with the Monroe suspension strut and coil spring assembly?
Monroe 173026 includes the strut, coil spring, upper strut mount, coil spring and strut mount insulators and mounting hardware. The strut, spring and mount arrive assembled.
How long is this strut assembly when extended and compressed?
Extended length is 22.52 in (572 mm) and compressed length is 14.74 in (374.4 mm), with 7.78 in of travel and a 14.37 in body length.
What wear should I look for before buying a Monroe complete strut assembly?
Look for fluid on the strut body, a clunk over bumps or heavy body sway while driving. A shop can test the strut if you are unsure.
Do I need a spring compressor to install Monroe 173026?
No. Monroe 173026 comes as a single, fully assembled unit with the strut, spring and mount already together, so a spring compressor is not needed.
