Spark Plug Wire Set for 1990-1997 Mazda Miata - NGK 9160

$68.99
WARNING:California Proposition 65▾

Vehicles this part fits

    Part number: 9160
    UPC: 087295091609
    Condition: New
    Weight: 1.40 LBS
    Item Package Quantity: 1
    $68.99
    Adding to cart… The item has been added

    Have questions?

    NGK Spark Plug Wire Set P/N:9160
    NGK Spark Plug Wire Set P/N:9160
    $68.99
    $68.99

    NGK 9160 spark plug wire set for the 1990-1993 Mazda Miata 4-cylinder 1.6L and the 1994-1997 Miata 4-cylinder 1.8L carries high-voltage current from the ignition coil to the spark plugs. This NGK wire is a variable pitch resistor cable that gives uniform resistance and good electrical conductivity.

    • Variable pitch magnetic core cable with winding over a ferrite magnetic alloy coating suppresses EMI/RFI noise across the frequency spectrum
    • Outer jacket withstands temperatures above 250 degrees C, with EPDM or silicone inner insulation for dielectric strength
    • Spark plug boots are glued to the cable with silicone sealer for a watertight seal
    • Stainless steel terminals with up to 3 serrated crimps bite into the cable jacket and inner insulation to hold the connection
    • Locking C-shaped spring clip with corrosion-resistant plating secures the spark plug terminal connection
    • Cylinder lead identification tags, where possible, make installation easier

    Quick facts

    • Part: NGK 9160 spark plug wire set
    • Fits: the 1990-1993 Mazda Miata 4-cylinder 1.6L and the 1994-1997 Miata 4-cylinder 1.8L

    A misfire, rough idle or hard starting can mean worn wires, though a worn spark plug or a failing ignition coil can be behind the same signs, so find the cause before replacing this set. Cracked or burned boots, seen with the engine off, are another sign of wear.

    Fits

    This NGK wire set fits the 1990-1993 Mazda Miata 4-cylinder 1.6L, the 1994-1997 Miata 4-cylinder 1.8L and the 1999-2000 Miata 4-cylinder 1.8L. The set holds four wires, and one set is all these engines take.

    Specifications

    Fit and size

    • Quantity per vehicle: 1 set
    • Wires in set: 4

    Build and materials

    • Cable type: variable pitch magnetic core resistor cable
    • Terminals: stainless steel
    • Spring clip: locking C-shaped, corrosion-resistant plating
    • NGK part number: RC-ZE21
    • Warranty: NGK limited lifetime warranty, details on the package

    Interchange: 175-6003 · 175-6070 · 35-4251 · 671-4220 · 35-PF77425 · RC-ZE21
    86520 · 96807 · CH7448 · 700478 · 09254 · 9254 · 127448 · 184012 · 55108 · 7491

    Product information is for general reference and may contain errors. See our Disclaimer.

    This part cross-references / interchanges with the following part numbers:

    RC-ZE21, 86520, 96807, CH7448, 175-6003, 175-6070, 700478, 09254, 9254, 35-4251, 671-4220, 9160, 127448, 35-PF77425, 184012, 55108, 7491

    Frequently Asked Questions

    Is NGK 9160 a Miata spark plug wire for the 1999-2000 Mazda Miata 4-cylinder 1.8L?

    Yes. NGK 9160 fits the 1999-2000 Mazda Miata 4-cylinder 1.8L, and one set of four wires is what that engine takes.

    Are NGK plug wires like this set resistor cables?

    Yes. NGK 9160 is a variable pitch resistor cable set with a magnetic core that suppresses EMI/RFI noise.

    What are the terminals on these wires made of?

    The terminals are stainless steel, with up to 3 serrated crimps that bite into the cable jacket and inner insulation. A locking C-shaped spring clip with corrosion-resistant plating holds the spark plug terminal.

    Do NGK spark plug wire sets like this one have cylinder ID tags?

    Yes, where possible. Cylinder lead identification tags are fitted to the leads and make installation easier.

    What warranty comes with NGK 9160?

    NGK backs this set with a limited lifetime warranty. The package has the details.
