Nugeon 97-02728A rear right brake caliper for the 2004-2008 Chrysler Crossfire and other vehicles clamps the brake pads against the rotor to slow the wheel. This remanufactured caliper has a fixed design with two pistons.
- Steel pistons with a 36 mm (1.417 in) diameter
- Cast iron caliper body with a rust-preventative finish
- Bleeder screw with an M8-1.25 thread
- Inlet port with an M10-1.0 thread
Quick facts
- Part: Nugeon 97-02728A brake caliper
- Also called: disc brake caliper
- Fits: 2004-2008 Chrysler Crossfire and other vehicles
- Position: Rear right
- Material: Cast iron body, steel pistons
- Condition: Remanufactured
Pulling to one side under braking, a burning smell at one wheel or pads that wear unevenly can mean a caliper is sticking or leaking. A worn rotor, a collapsed brake hose or seized slide pins can be behind the same signs, so find the cause before buying a caliper.
Fits
This caliper is listed for a wide range of Chrysler and Mercedes-Benz models, led by the 2004-2008 Chrysler Crossfire, the 1998-2004 Mercedes-Benz SLK230 and the 2001-2004 Mercedes-Benz SLK320. Each side of the rear axle has its own caliper: this listing is the right one, the left is a separate part, and both are normally done at the same time.
Specifications
Fit and size
- Position: Rear right
- Quantity per side: 1
- Piston quantity: 2
- Piston diameter: 36 mm (1.417 in)
- Inlet port thread: M10-1.0
- Bleeder screw thread: M8-1.25
- Housing cast numbers: 16 / 36/278
Build and materials
- Caliper type: Fixed
- Casting material: Cast iron
- Piston material: Steel
- Finish: Rust preventative
- Condition: Remanufactured
- Country of origin: Mexico
In the box
One remanufactured brake caliper with its bleeder screw, dust boots, mounting hardware and crush washers. Brake pads, the bracket, caliper slides, pad hardware, anti-squeal shims, wear sensors, the bleeder screw cap and the mounting and bracket bolts are not included, so plan on new bolts.
Frequently Asked Questions
Is the Nugeon 97-02728A caliper right for the 2004-2008 Chrysler Crossfire?
Yes, Nugeon 97-02728A is a rear right brake caliper listed for the 2004-2008 Chrysler Crossfire. If your car is a different model, look for it in the "Vehicles it fits" section on this page.
Do brake pads and the bracket come with this Nugeon brake caliper?
No. Nugeon 97-02728A is one remanufactured caliper with its bleeder screw, dust boots, mounting hardware and crush washers. Pads, the bracket and the bracket bolts are sold separately.
What piston size does this rear right caliper have?
This fixed caliper has two steel pistons with a 36 mm (1.417 in) piston diameter. The body is cast iron with a rust-preventative finish.
How do I tell if a disc brake caliper on the rear right is sticking?
Pulling to one side, a burning smell near one wheel or unevenly worn pads can be signs. A shop can test it, so have the brakes checked promptly rather than driving on them.
What thread does the bleeder screw on this Nugeon caliper use?
The bleeder screw on Nugeon 97-02728A has an M8-1.25 thread. The inlet port uses an M10-1.0 thread.
