Front Left Brake Caliper for 2015-2020 Chevrolet Colorado & More - TERREPOWER 97P17475B
TERREPOWER 97P17475B front left brake caliper for the 2015-2020 Chevrolet Colorado and other vehicles clamps the brake pads against the rotor to slow the wheel. This remanufactured fixed caliper is also called a disc brake caliper.
- Fixed caliper with four steel pistons, 44 mm (1.73 in) in diameter
- Cast iron caliper casting with an E-coated finish
- Banjo bolt inlet with an M10-1.0 x 27.32 inlet port thread
- M10-1.0 bleeder screw with a bleeder screw cap
Quick facts
- Part: TERREPOWER 97P17475B brake caliper
- Also called: disc brake caliper
- Fits: 2015-2020 Chevrolet Colorado and other vehicles
- Position: Front left
- Material: Cast iron caliper casting, steel pistons
- Condition: Remanufactured
A pull to one side under braking, uneven pad wear or fluid around the dust boot can mean a caliper is sticking or leaking. Before you replace it, rule out a worn brake hose or worn pads first, since either can also make the car pull. Calipers are normally replaced as a pair across the axle, and this listing is one caliper for the front left; the front right is a separate part.
Fits
It fits the 2015-2020 Chevrolet Colorado and the 2015-2020 GMC Canyon. The 2015-2020 Chevrolet Colorado takes one front left caliper.
Specifications
Fit and size
- Position: Front left
- Quantity per vehicle: 1
- Piston quantity: 4
- Piston diameter: 44 mm (1.73 in)
- Inlet fitting: Banjo bolt, M10-1.0 x 27.32 inlet port thread
- Bleeder screw: M10-1.0
- Housing cast number: 4505
Build and materials
- Condition: Remanufactured
- Caliper type: Fixed
- Casting material: Cast iron
- Piston material: Steel
- Finish: E-coated
- Caliper manufacturer: Akebono
- Country of origin: Mexico
In the box
One remanufactured front left brake caliper with a bleeder screw and cap, dust boots, caliper and pad hardware, mounting hardware and a crush washer. Brake pads, the bracket, bracket mounting bolts, the mounting bolt, caliper slides, anti-squeal shims and wear sensors are not included, so plan on new mounting bolts.
Interchange / FMSI:
FMSI: D1802
Frequently Asked Questions
Is this a Chevy Colorado brake caliper for the 2015-2020 model years?
Yes. TERREPOWER 97P17475B is the front left caliper for the 2015-2020 Chevrolet Colorado, and it also fits the 2015-2020 GMC Canyon.
Does this front left brake caliper include the bleeder screw and dust boots?
Yes. TERREPOWER 97P17475B comes with the bleeder screw and cap, dust boots, caliper and pad hardware, mounting hardware and a crush washer. Pads and the bracket are not included.
What inlet fitting does this brake caliper use?
It has a banjo bolt inlet with an M10-1.0 x 27.32 inlet port thread, and a crush washer is included. The bleeder screw is M10-1.0.
How can I tell whether a front brake caliper is sticking or leaking?
A pull to one side when braking, uneven pad wear or brake fluid around the dust boot can mean a sticking or leaking caliper. A shop can test it, and a leak should be looked at promptly.
Is the TERREPOWER 97P17475B brake caliper new or remanufactured?
It is remanufactured, with a cast iron caliper casting, steel pistons and an E-coated finish. The caliper manufacturer is Akebono, and the country of origin is Mexico.
