TERREPOWER 99P02014A front left brake caliper for the 2019-2024 Mazda CX-5 and other vehicles presses the pads against the rotor to slow the wheel. This remanufactured caliper has a cast iron housing and an E-coated finish.
- Floating caliper type
- Two phenolic pistons, each 45 mm (1.77 in) across
- Banjo bolt inlet fitting with an M10 - 1.0 thread
- Bleeder screw with an M10-1.0 thread and a screw cap
Quick facts
- Part: TERREPOWER 99P02014A brake caliper
- Also called: disc brake caliper
- Fits: 2019-2024 Mazda CX-5 and other vehicles
- Position: Front left
- Material: Cast iron
- Condition: Remanufactured
Worn pads, a worn rotor or a damaged brake hose can be behind pulling to one side under braking or fluid around the caliper, as can a sticking or leaking caliper, so find the cause before buying. Calipers are normally replaced as a pair across an axle; this listing is one front left caliper, and the front right is a separate part.
Fits
This brake caliper fits the 2019-2024 Mazda CX-5 and the 2016-2023 Mazda CX-9, and each takes one at the front left.
Specifications
Fit and size
- Position: front left
- Quantity per vehicle: 1
- Piston diameter: 45 mm (1.77 in)
- Piston quantity: 2
- Inlet thread size: M10 - 1.0
- Bleeder screw thread: M10-1.0
- Housing cast number: F13WT K0089
- Bracket cast number: F13WT 17
Build and materials
- Caliper type: floating
- Housing material: cast iron
- Piston material: phenolic
- Finish: E-coated
- Inlet fitting: banjo bolt
- Condition: remanufactured
- Country of origin: Mexico
In the box
One front left caliper with its mounting bracket, caliper slides, dust boots, caliper and pad hardware, bleeder screw and cap, one banjo bolt and crush washers. Brake pads, anti-squeal shims, wear sensors and bracket mounting bolts are not included; plan on new bolts rather than reusing the old ones.
Interchange / FMSI:
FMSI: D1258
Frequently Asked Questions
Is this a brake caliper for the 2016-2023 Mazda CX-9?
Yes. TERREPOWER 99P02014A is a front left caliper that fits the 2016-2023 Mazda CX-9, and that vehicle takes one on this side.
Does the TERREPOWER 99P02014A caliper come with brake pads?
No. Pads, anti-squeal shims, wear sensors and bracket mounting bolts are not included. The bracket, slides, dust boots and bleeder screw are.
Is this disc brake caliper floating or fixed?
This front left caliper is a floating type with two phenolic pistons, each 45 mm (1.77 in) in diameter.
What size is the banjo bolt inlet on the TERREPOWER 99P02014A?
The TERREPOWER 99P02014A inlet is a banjo bolt fitting with an M10 - 1.0 thread. One banjo bolt and crush washers are included, and the bleeder screw is M10-1.0.
What finish does this remanufactured caliper have?
The cast iron housing has an E-coated finish, and the pistons are phenolic.
