CARDONE New 3P-53109 power steering pump pulley for the 1995-2003 Toyota Camry and other vehicles turns the steering pump from the engine belt. It is a direct replacement for the original pulley and is tested to meet the same performance as O.E.
- Plastic pulley with a 112.4 mm (4.425 in) outside diameter
- 16.4 mm (0.644 in) wide, with a 14.3 mm (0.563 in) bore
- One mounting hole
Quick facts
- Part: CARDONE New 3P-53109 power steering pump pulley
- Fits: 1995-2003 Toyota Camry and other vehicles
- Material: Plastic
- Condition: New
A worn pulley can show up as wobble, cracks or chips, or a noisy belt. Before you replace the pulley, rule out a worn or loose drive belt and a failing steering pump, since either can make similar noises. The pulley is also worth replacing during any power steering pump service.
Fits
It is listed for a wide range of Toyota and Lexus models, including the 1998-2003 Toyota Sienna and the 2001 Toyota Highlander. Open the "Vehicles it fits" section to check your exact model and engine.
Specifications
Fit and size
- Outside diameter: 112.4 mm (4.425 in)
- Width: 16.4 mm (0.644 in)
- Bore diameter: 14.3 mm (0.563 in)
- Shaft diameter: 14.3 mm (0.563 in)
- Mounting holes: 1
- Quantity per vehicle: 1
Build and materials
- Material: Plastic
- Condition: New
- Country of origin: China
In the box
The box holds one pulley, which is also the number your car takes. Mounting hardware is not included, so plan on new hardware where one is needed.
Installation notes
- The correct tool for the engine application and pulley type is necessary to prevent damage to the pulley.
- Press the replacement pulley on until the hub is flush with the end of the shaft.
Interchange: 4431107020
Product information is for general reference and may contain errors. See our Disclaimer.
Frequently Asked Questions
Does the CARDONE New 3P-53109 power steering pump pulley fit the 1998-2003 Toyota Sienna?
Yes, CARDONE New 3P-53109 is listed for the 1998-2003 Toyota Sienna. Open the "Vehicles it fits" section to check another model and engine.
Does the 3P-53109 pulley come with mounting hardware?
No. This listing is one pulley only; mounting hardware is not included.
What is the CARDONE New 3P-53109 pulley made of, and how big is it?
It is plastic. The CARDONE New 3P-53109 measures 112.4 mm across and 16.4 mm wide, with a 14.3 mm bore.
Do I need a special tool to put this pulley on the pump shaft?
Yes, the correct tool for your engine application and pulley type is necessary, because the wrong one can damage the pulley. Press the new pulley on until its hub sits flush with the shaft end.
Does 4431107020 interchange with this power steering pump pulley?
Yes. 4431107020 is listed as an interchange number for CARDONE New 3P-53109.
