Rear Shock Absorber for 2007-2017 Jeep Wrangler & More - Rancho Suspension RS994328

$165.99

Vehicles this part fits

    Part number: RS994328
    UPC: 039703017695
    Condition: New
    Weight: 6.50 LBS
    Item Package Quantity: 1
    $165.99
    Adding to cart… The item has been added

    Have questions?

    Rancho Suspension Shock Absorber P/N:RS994328
    Rancho Suspension Shock Absorber P/N:RS994328
    $165.99
    $165.99

    Rancho Suspension RS994328 rear shock absorber for the 2007-2017 Jeep Wrangler and other vehicles damps rear suspension movement and has a nine-position damping knob. The RS9000XL series is made for stock or lifted vehicles that tow, haul or go off road.

    • Rancho RS9000XL series, now in its fourth generation, with integrated bottom mounts for strength
    • Nine-position knob sets damping and firmness for on-road and off-road use
    • Nitrogen gas pressurized to 45 or 60 PSI to reduce damping fade and foaming
    • Tri-tube body up to 2.38 in. with all-weather fluid for internal temperatures of -40 to 248°F
    • Polyurethane rebound bumper and bushings with a graphite-filled fluon-banded piston to absorb ride harshness
    • Dual component 2K paint finish that resists chipping

    Quick facts

    • Part: Rancho Suspension RS994328 shock absorber
    • Also called: suspension shock absorber
    • Fits: 2007-2017 Jeep Wrangler and other vehicles
    • Position: Rear
    • Material: Steel
    • Condition: New

    A bouncy rear ride, fluid on the shock body or a clunk over bumps can mean a shock is worn, but other suspension parts can produce those signs too. Before replacing it, check the shock body with the engine off for oil film or dents and the bushings for cracked rubber. This listing is one shock, and the other side is normally replaced at the same time. The rear axle takes one on each side.

    Fits

    It is a shock absorber for the 2007-2017 Jeep Wrangler and the 2018 Jeep Wrangler JK, a direct-fit replacement for these vehicles.

    Specifications

    Fit and size

    • Position: Rear
    • Quantity per vehicle: 2
    • Compressed length: 376.4 mm (14.82 in)
    • Extended length: 574 mm
    • Travel length: 197.6 mm (7.78 in)
    • Body diameter: 54 mm (2.13 in)
    • Bore size: 32 mm (1.26 in)
    • Rod diameter: 16 mm (0.63 in)
    • Dust shield diameter: 75.9 mm (2.99 in)
    • Upper mount: cross pin
    • Lower mount: loop (eyelet) bushing and sleeve

    Build and materials

    • Body material: Steel
    • Finish: Painted
    • Damping adjustment: Manual, compression and rebound
    • Valving: Progressive
    • Condition: New
    • Warranty: Rancho Limited Lifetime Warranty
    • Country of origin: Australia

    In the box

    One rear shock absorber with its protective boot. Coil springs are not included.

    Interchange: 52126751AC · 52126851AB · 68003310AB · 68027797AA · 68028455AC · 68029960AA · 68047814AA · 68047814AB · 68067515AA · 68067515AC · 68087363AB · 68087363AC · 68138853AA · 68138853AB · RS999327 · RS999328

    Product information is for general reference and may contain errors. See our Disclaimer.

    This part cross-references / interchanges with the following part numbers:

    52126751AC, 52126851AB, 68003310AB, 68027797AA, 68028455AC, 68029960AA, 68047814AA, 68047814AB, 68067515AA, 68067515AC, 68087363AB, 68087363AC, 68138853AA, 68138853AB, RS999327, RS999328

    Frequently Asked Questions

    Does the Rancho RS994328 fit the 2018 Jeep Wrangler JK?

    Yes. Rancho Suspension RS994328 is a rear shock absorber for the 2018 Jeep Wrangler JK and the 2007-2017 Jeep Wrangler. The rear axle takes two, one per side.

    Does the RS994328 come with springs or just the shock?

    Rancho Suspension RS994328 is one rear shock absorber with its protective boot. Coil springs and spring seats are not included.

    What does the nine-position knob on this suspension shock absorber change?

    The knob sets damping and firmness, so the shock can be tuned for on-road or off-road use. The nitrogen charge of 45 or 60 PSI helps reduce fade and foaming.

    What does fluid on a rear shock body mean?

    Oil film on the body, a bouncy ride or a clunk over bumps can mean a shock is worn. Other suspension parts can cause similar signs, so a shop can confirm the cause.

    What temperature range can this shock handle?

    The all-weather fluid in the tri-tube body is rated to withstand internal temperatures of -40 to 248°F.
