Piston Set for 1987-1990 Jeep Wrangler & More - Sealed 470AP 60

$299.99

Vehicles this part fits

    Part number: 470AP60
    UPC: 614046896819
    Condition: New
    Weight: 4.49 LBS
    Pack of 6
    $299.99
    Adding to cart… The item has been added

    Have questions?

    Sealed Power Engine Piston Set P/N:470AP 60 (Pack of 6)
    Sealed Power Engine Piston Set P/N:470AP 60 (Pack of 6)
    $299.99
    $299.99

    Sealed 470AP 60 piston set for the 1987-1990 Jeep Wrangler 6-cylinder 4.2L and other vehicles turns combustion pressure into force on the connecting rods. This engine piston set is oversized by 0.060 in and meets or exceeds OEM specifications.

    • Cast aluminum piston made with FM132 eutectic proprietary alloy
    • Recessed piston head
    • Compression rings 0.0781 in thick and an oil ring 0.1875 in thick
    • Pin offset of 0.06 in (1.524 mm)

    Quick facts

    • Part: Sealed 470AP 60 piston set
    • Also called: engine piston set
    • Fits: 1987-1990 Jeep Wrangler 6-cylinder 4.2L and other vehicles
    • Material: cast aluminum

    Worn pistons can show up as oil consumption, blue exhaust smoke or lost compression. These signs alone do not prove the pistons are the problem, since worn valve seals can burn oil too.

    Fits

    The vehicles it fits include the 1987-1990 Jeep Wrangler 6-cylinder 4.2L, the 1979-1983 Jeep Cherokee 6-cylinder 4.2L and the 1980-1988 American Motors Eagle 6-cylinder 4.2L. The 1987-1990 Jeep Wrangler 6-cylinder 4.2L takes six.

    Specifications

    Fit and size

    • Oversize: 0.060 in
    • Bore diameter: 3.7500 in
    • Piston pin outside diameter: 0.9313 in (23.655 mm)
    • Compression height: 1.633 in
    • Quantity per vehicle: 6

    Build and materials

    • Piston head type: Recessed
    • Material: cast aluminum
    • Country of origin: Mexico

    In the box

    The piston set. Assembly lubricant is not included.

    Interchange: 224-5158.060
    P837060 · 92227060 · TC2158060 · 1147P60 · 9042P60 · 2227060 · 2227P060 · L3103F60

    Product information is for general reference and may contain errors. See our Disclaimer.

    This part cross-references / interchanges with the following part numbers:

    P837060, 92227060, TC2158060, 1147P60, 224-5158.060, 9042P60, 2227060, 2227P060, L3103F60

    Frequently Asked Questions

    Is the Sealed 470AP 60 piston set right for a 1987-1990 Jeep Wrangler 6-cylinder 4.2L?

    Yes, Sealed 470AP 60 fits the 1987-1990 Jeep Wrangler 6-cylinder 4.2L, which takes six. If your car is not named here, look it up in the "Vehicles it fits" section on this page.

    What bore diameter and oversize does this 470AP 60 piston set have?

    Sealed 470AP 60 lists a 3.7500 in bore diameter and is oversized by 0.060 in. The cylinder bores need to be machined to suit an oversize piston, which a machine shop can do.

    Does this piston set come with assembly lubricant?

    No. Assembly lubricant is not included with this piston set, so it has to be bought separately.

    Are these pistons cast aluminum?

    Yes, this piston set is cast aluminum, made with FM132 eutectic proprietary alloy, and has a recessed head.

    What piston pin diameter and compression height should I expect?

    The piston pin outside diameter is 0.9313 in (23.655 mm) and the compression height is 1.633 in.
