Piston Set for 1993-1995 Jeep Grand Cherokee & More - Sealed 677AP 30

$353.99

Vehicles this part fits

    Part number: 677AP30
    UPC: 614046935365
    Condition: New
    Weight: 4.49 LBS
    Pack of 6
    $353.99
    Adding to cart… The item has been added

    Have questions?

    Sealed Power Engine Piston Set P/N:677AP 30 (Pack of 6)
    Sealed Power Engine Piston Set P/N:677AP 30 (Pack of 6)
    $353.99
    $353.99

    Sealed 677AP 30 piston set for the 1993-1995 Jeep Grand Cherokee 6-cylinder 4.0L and other vehicles transfers combustion force to the connecting rod. It meets or exceeds OEM specifications.

    • Cast with FM132 eutectic proprietary alloy
    • Cast aluminum pistons with a recessed head
    • 0.030 inch oversize for a 3.8750 inch bore diameter
    • 0.931 inch (23.647 mm) piston pin outside diameter with a 0.06 inch (1.524 mm) pin offset

    Quick facts

    • Part: Sealed 677AP 30 piston set
    • Also called: engine piston set
    • Fits: 1993-1995 Jeep Grand Cherokee 6-cylinder 4.0L and other vehicles
    • Material: Cast aluminum
    • Condition: New

    Worn pistons and rings can show up as oil burning, loss of compression or a knock from the engine. Before you replace the pistons, rule out other sources of those same signs, such as valve seals or a head gasket, so you are not rebuilding for the wrong reason.

    Fits

    The vehicles it fits include the 1993-1995 Jeep Grand Cherokee 6-cylinder 4.0L, the 1991-1995 Jeep Wrangler 6-cylinder 4.0L and the 1987-1995 Jeep Cherokee 6-cylinder 4.0L, and each takes six pistons. Owners of other Jeeps can look up their year and engine in the "Vehicles it fits" section.

    Specifications

    Fit and size

    • Quantity per vehicle: 6
    • Bore diameter: 3.8750 in
    • Oversize: 0.030 in
    • Piston pin outside diameter: 0.931 in (23.647 mm)
    • Pin offset: 0.06 in (1.524 mm)
    • Compression height: 1.585 in
    • Compression ring thickness, top and second: 0.0781 in
    • Oil ring thickness: 0.1875 in

    Build and materials

    • Material: Cast aluminum
    • Head type: Recessed
    • Condition: New
    • Country of origin: India

    In the box

    The piston set. Assembly lubricant is not included.

    Interchange: P1120.30 · P1593(6)030 · 224-2322.030

    Product information is for general reference and may contain errors. See our Disclaimer.

    This part cross-references / interchanges with the following part numbers:

    P1120.30, P1593(6)030, 224-2322.030

    Frequently Asked Questions

    Does the Sealed 677AP 30 piston set fit a 1993-1995 Jeep Grand Cherokee 6-cylinder 4.0L?

    Yes. Sealed 677AP 30 fits the 1993-1995 Jeep Grand Cherokee 6-cylinder 4.0L, and that engine takes six pistons. Other Jeeps are in the "Vehicles it fits" section.

    Is this engine piston set oversize, and by how much?

    Yes. Sealed 677AP 30 is 0.030 inch oversize, with a bore diameter of 3.8750 inches.

    What piston pin size do the 677AP 30 pistons use?

    The piston pin outside diameter is 0.931 inch (23.647 mm), and the pin offset is 0.06 inch (1.524 mm).

    Does this piston set come with assembly lubricant?

    No. Assembly lubricant is not included with this piston set.

    Does the 677AP 30 replace piston set P1120.30?

    Yes. P1120.30 is one of the numbers the 677AP 30 replaces, along with P1593(6)030 and 224-2322.030.
