Engine Piston for 1997-2006 Jeep Wrangler & More - Sealed H802CP 30

$319.99

Vehicles this part fits

    Part number: H802CP30
    UPC: 614046344341
    Condition: New
    Weight: 4.49 LBS
    Pack of 6
    $319.99
    Adding to cart… The item has been added

    Have questions?

    Sealed Power Engine Piston Set P/N:H802CP 30 (Pack of 6)
    Sealed Power Engine Piston Set P/N:H802CP 30 (Pack of 6)
    $319.99
    $319.99

    Sealed H802CP 30 engine piston for the 1997-2006 Jeep Wrangler 6-cylinder 4.0L and other vehicles turns combustion pressure into force on the connecting rod. This is a 0.030 in oversize set, so the cylinders must be sized to match it.

    • Helps improve cylinder sealing for less blow-by
    • Retains standard ring gaps in the top groove
    • DUROSHIELD skirt-coated piston
    • Moly-graphite coating extends engine life
    • Reduces friction to help fuel economy
    • Helps prevent damage from inadequate lubrication on start-up

    Quick facts

    • Part: Sealed H802CP 30 engine piston
    • Fits: the 1997-2006 Jeep Wrangler 6-cylinder 4.0L and other vehicles
    • Material: Hypereutectic
    • Condition: New

    Worn pistons and rings can show up as oil use, blow-by or low compression, and worn bores or valves can look the same. Before replacing them, look over the bores for scoring and measure them with the engine apart and cool; a shop can run compression and leak-down tests.

    Fits

    This hypereutectic cast piston set also fits the 1996-2004 Jeep Grand Cherokee 6-cylinder 4.0L and the 1996-2001 Jeep Cherokee 6-cylinder 4.0L.

    Specifications

    Fit and size

    • Oversize: 0.030 in
    • Bore diameter: 3.8750 in
    • Compression height: 1.592 in
    • Piston pin outside diameter: 0.931 in (23.647 mm)
    • Pin offset: 0.06 in (1.524 mm)
    • Ring thickness: top compression 1.50 mm, second compression 1.50 mm, oil 4.00 mm
    • Quantity per vehicle: 6

    Build and materials

    • Type: cast piston set
    • Material: hypereutectic
    • Head type: recessed
    • Skirt: DUROSHIELD coated
    • Condition: new
    • Country of origin: India

    In the box

    One set of pistons. A 6-cylinder 4.0L engine takes six pistons. Assembly lubricant is not included.

    Installation notes

    • Minimum clearance: see the piston fitting information on the carton label.

    Interchange: P1123.30 · P3071(6)030 · 224-3415.030
    TC3415030 · ZC7061030

    Product information is for general reference and may contain errors. See our Disclaimer.

    This part cross-references / interchanges with the following part numbers:

    TC3415030, P1123.30, P3071(6)030, 224-3415.030, ZC7061030

    Frequently Asked Questions

    Is the Sealed H802CP 30 piston set right for a 1996-2004 Jeep Grand Cherokee 6-cylinder 4.0L?

    Yes, Sealed H802CP 30 fits the 1996-2004 Jeep Grand Cherokee 6-cylinder 4.0L. If your Jeep is a different one, find your year and engine in the "Vehicles it fits" section before ordering.

    What oversize is the Sealed H802CP 30 piston set?

    Sealed H802CP 30 is 0.030 in oversize, with a listed bore diameter of 3.8750 in. The cylinder bores need to be sized to match that oversize.

    What is this hypereutectic piston made of, and is it coated?

    The piston material is hypereutectic, with a DUROSHIELD-coated skirt and a moly-graphite coating that reduces friction.

    Does this piston set include assembly lubricant?

    No, assembly lubricant is not included with this piston set, so plan to supply your own.

    Where do I find the piston clearance for the Sealed H802CP 30?

    The minimum clearance is in the piston fitting information printed on the carton label that comes with the Sealed H802CP 30 set.
