Standard Ignition IPL2 fuel feed line for the 2015 Ford F-250 Super Duty V8 6.7L and other vehicles supplies fuel at injection pressure to the injectors. Also sold as a diesel injection pump supply line, it is a direct-fit replacement for a damaged unit and includes a fuel pressure sensor.
- High-temp Viton o-rings for sealing under extreme heat
- Fuel pressure sensor included with the line
- Connectors and terminals made for an exact connection to the engine wiring harness
- Industrial-grade materials for a prolonged service life
- Molded design in metal and plastic
Quick facts
- Part: Standard Ignition IPL2 fuel feed line
- Fits: 2015 Ford F-250 Super Duty V8 6.7L and other vehicles
- Material: Metal, plastic
- Condition: New
Fuel odor, seepage at the line or its o-rings, hard starting or rough running can mean the line is leaking or failing. These signs alone do not prove this line is the problem, because a clogged fuel filter can bring on the same symptoms. A shop can test a suspected fuel leak.
Fits
The 2015 Ford F-250 Super Duty V8 6.7L, 2015 Ford F-350 Super Duty V8 6.7L and 2015 Ford F-450 Super Duty V8 6.7L are among the vehicles this line fits. The 2015 Ford F-250 Super Duty V8 6.7L takes one. If your vehicle is not named here, find it in the "Vehicles it fits" section.
Specifications
Fit and size
- Quantity per vehicle: 1
- Length: 631.825 mm (24.875 in)
- Inner diameter: 7.71 mm (0.303 in)
- Port quantity: 5
- Terminal quantity: 4
Build and materials
- Material: Metal, plastic
- Construction: Molded
- Terminals: Blade, male; connector gender: male
- O-rings: High-temp Viton
- Fuel pressure sensor: included
- Condition: New
- Country of origin: United States
In the box
One fuel feed line with its fuel pressure sensor. Gaskets and hardware are not included, so plan on new ones rather than reusing the old.
Interchange: 800-94701
ISL2 · PSL235 · FC3Z9J280A · FC3Z9J280B
Product information is for general reference and may contain errors. See our Disclaimer.
This part cross-references / interchanges with the following part numbers:
ISL2, PSL235, FC3Z9J280A, FC3Z9J280B, 800-94701
Frequently Asked Questions
Does the Standard Ignition IPL2 fuel feed line fit a 2015 Ford F-350 Super Duty V8 6.7L?
Yes. Standard Ignition IPL2 is listed for the 2015 Ford F-350 Super Duty V8 6.7L. If your truck is a different model, look it up in the "Vehicles it fits" section.
Does the IPL2 fuel feed line come with the fuel pressure sensor and gaskets?
Yes to the sensor: Standard Ignition IPL2 includes a fuel pressure sensor. No to gaskets and hardware, which are not included.
What is the inner diameter of this fuel feed line?
The inner diameter is 7.71 mm (0.303 in). The line is 631.825 mm (24.875 in) long and has 5 ports.
What are the o-rings on this fuel feed line made of?
They are high-temp Viton o-rings, which hold a seal under extreme heat. The line itself is made of metal and plastic.
Is Standard Ignition IPL2 an interchange for FC3Z9J280A?
Yes. FC3Z9J280A is one of the other-brand and OE numbers Standard Ignition IPL2 replaces; the rest are on the Interchange line.
