Mevotech Supreme Suspension Control Arm and Ball Joint Assembly P/N:CMS86142
Mevotech Supreme CMS101055 front right upper control arm with ball joint for the 2006-2013 Mercedes-Benz R350 and other vehicles connects the wheel hub to the chassis at the ball joint. This Mevotech Supreme suspension control arm is also called a control arm and ball joint assembly.
A clunk or knock from the front suspension, uneven tire wear or loose-feeling steering can mean the ball joint or bushings have worn. Before you replace the arm, rule out worn links, tie rod ends or shock mounts that can make similar noises.
This part is listed for a wide range of Mercedes-Benz models, including the 2006-2013 Mercedes-Benz R350, the 2010-2012 Mercedes-Benz GL350 and the 2007-2012 Mercedes-Benz GL450. The aluminum arm meets or exceeds OE specifications. This listing is one front right upper arm, which is what that position takes; the front left upper arm is a separate part ordered on its own, and the two sides are normally replaced together. Owners of other Mercedes-Benz models can look up their year and model in the "Vehicles it fits" section.
Fit and size
Build and materials
One control arm with ball joint, bushings, mounting hardware and a part-specific locking nut.
Interchange: 101-7077 · 102-7077 · 521-522 · 016 050 0001
19310378 · LGS101055 · TC2950 · CB28098 · CB28098PR · CA8624 · 3CB10450 · CAK620982 · RK620982 · RK641502 · C5GS101055 · 2513300807 · A2513300807 · GS101055 · 2606644 · 1550101 · 30036088 · X31CJ2463 · JTC2465
Product information is for general reference and may contain errors. See our Disclaimer.
This part cross-references / interchanges with the following part numbers:
Is this the right Mercedes R350 control arm for a 2006-2013 Mercedes-Benz R350?
Yes. Mevotech Supreme CMS101055 is the front right upper control arm with ball joint listed for the 2006-2013 Mercedes-Benz R350. The left side takes its own separate arm.
Will this Mercedes GL450 control arm work on a 2007-2012 Mercedes-Benz GL450?
Yes. The 2007-2012 Mercedes-Benz GL450 is in the fitment for this front right upper position, and the position takes one arm.
Does the CMS101055 control arm come with bushings and a locking nut?
Yes. Mevotech Supreme CMS101055 includes rubber bushings, mounting hardware and a part-specific locking nut for the threaded ball joint stud.
Is this front right upper control arm aluminum or steel?
Aluminum, with rubber bushings. At its maximum the control arm measures 11.5 inches wide by 14.25 inches long.
What does the extra surface treatment on this ball joint do?
The additional surface treatment on the ball joint is there to prevent rust build-up, which supports a longer ball joint life.
