Mevotech Supreme CMS801200 rear right upper control arm with ball joint for the 2008-2013 Subaru Forester and other vehicles connects the wheel to the vehicle body and pivots on its ball joint. The ball joint comes with the arm as one assembly.
- Mevotech Supreme line, engineered in-house with application-specific upgrades
- Steel control arm with sintered metal bearings
- 180 degree SAE grease fitting included for servicing
- Protective surface treatment helps prevent rust build-up
- Neoprene dust boot included
Quick facts
- Part: Mevotech Supreme CMS801200 control arm with ball joint
- Also called: control arm and ball joint assembly
- Fits: 2008-2013 Subaru Forester and other vehicles
- Position: Rear right upper
- Material: Steel
- Condition: New
A clunk over bumps, uneven tire wear or a loose feel from the rear right can mean a worn arm or ball joint. A rear shock, a wheel bearing, a stabilizer link or an alignment problem can be behind these signs too, so find the cause before buying.
Fits
This is a control arm for the 2008-2013 Subaru Forester and the 2010-2019 Subaru Outback. The listing is one arm for the rear right upper position; the left side of that axle is a separate part, and both sides are normally replaced together.
Specifications
Fit and size
- Position: Rear right upper
- Quantity: 1, this side only
- Ball joint mounting type: Press in
Build and materials
- Type: Control arm with ball joint
- Control arm material: Steel
- Bearing material: Sintered metal
- Dust boot material: Neoprene
- Pre-greased and greaseable
- Condition: New
- Country of origin: China
In the box
One control arm with the ball joint and dust boot, plus the grease fitting, pinch bolt and locking nut.
Interchange: 19429455 · TC8309 · RK623394 · 2608716 · 20252AJ02A · 20252AL02A · 20252SC000
This part cross-references / interchanges with the following part numbers:
Frequently Asked Questions
Is this the right control arm for the 2008-2013 Subaru Forester?
Yes. Mevotech Supreme CMS801200 is the rear right upper control arm with ball joint for the 2008-2013 Subaru Forester and also fits the 2010-2019 Subaru Outback.
What hardware comes with the control arm and ball joint assembly?
The pinch bolt and locking nut for the ball joint are included, along with a 180 degree SAE grease fitting and the neoprene dust boot.
Is this Mevotech Supreme suspension control arm greaseable?
Yes. CMS801200 is pre-greased and greaseable, and the 180 degree SAE grease fitting is included for later servicing.
What upgrades does this Mevotech Supreme control arm have?
It has a steel control arm, sintered metal bearings and a protective surface treatment that helps prevent rust build-up.
How can I tell if the ball joint on this rear upper control arm is worn?
A clunk over bumps, uneven tire wear or a torn dust boot can mean wear. A shop can measure the play in the joint.
