Front Left Lower Control Arm with Ball Joint for 2002-2003 Chevrolet Trailblazer & More - Dorman 526-633

$264.99

Vehicles this part fits

    Part number: 526-633
    UPC: 889245210326
    Condition: New
    Weight: 32.30 LBS
    Item Package Quantity: 1
    $264.99
    Adding to cart… The item has been added

    Have questions?

    Dorman - OE Solutions Suspension Control Arm and Ball Joint Assembly P/N:526-633
    Dorman - OE Solutions Suspension Control Arm and Ball Joint Assembly P/N:526-633
    $264.99
    $264.99

    Dorman 526-633 front left lower control arm with ball joint for the 2002-2003 Chevrolet Trailblazer and other vehicles links the front left wheel to the frame. If worn bushings or a loose ball joint cause a clunk over bumps, this control arm and ball joint assembly replaces both.

    • Part of Dorman's OE Solutions line
    • Tested through an evaluation process aimed at a smooth ride, directional stability and predictable dynamics
    • Ball joint and bushings pre-installed, saving time and labor
    • Additional coatings for rust and corrosion resistance
    • Boxed steel arm with a pre-greased, threaded-stud ball joint

    Quick facts

    • Part: Dorman 526-633 control arm with ball joint
    • Also called: control arm and ball joint assembly
    • Fits: 2002-2003 Chevrolet Trailblazer and other vehicles
    • Position: Front left lower
    • Material: Steel
    • Condition: New

    Uneven tire wear or loose steering can be other signs of a worn arm. Before you replace it, rule out a worn tie rod end, sway bar link or strut mount, since each can cause similar noises or handling changes. Both front lower arms normally get replaced together; this listing is one arm for the front left, and the front right is ordered separately.

    Fits

    This front left lower control arm is a direct replacement for the original equipment on the 2002-2003 Chevrolet Trailblazer, the 2002-2003 Chevrolet Trailblazer EXT, the 2002-2003 GMC Envoy and other vehicles. The 2002-2003 Chevrolet Trailblazer takes one on the front left. To see whether your own car is covered, look up its year and model in the "Vehicles it fits" section.

    Specifications

    Fit and size

    • Position: Front left lower
    • Mounting holes: 5, with diameters of 26 mm and 20 mm
    • Control arm maximum width: 358.46 mm
    • Control arm maximum length: 396.5 mm
    • Ball joint stud length: 34.58 mm
    • Ball joint thread diameter: 16 mm

    Build and materials

    • Control arm: boxed construction, steel
    • Bushing material: steel and rubber
    • Ball joint: press-in mounting, threaded stud, pre-greased
    • Condition: New
    • Country of origin: Taiwan

    In the box

    One control arm, one ball joint and one nut, with mounting hardware included. A grease fitting is not included.

    Interchange: TC6282 · CA16315 · 15072943 · 15091389 · 15105775 · 15165150 · 15167262 · 15183144 · 15198486 · 19133553 · 89060576 · RK620310 · GS50154 · CMS50154 · 2606019 · 12CB50094 · JTC2402

    Product information is for general reference and may contain errors. See our Disclaimer.

    This part cross-references / interchanges with the following part numbers:

    TC6282, CA16315, 15072943, 15091389, 15105775, 15165150, 15167262, 15183144, 15198486, 19133553, 89060576, RK620310, GS50154, CMS50154, 2606019, 12CB50094, JTC2402

    Frequently Asked Questions

    Is Dorman 526-633 the right control arm for the 2002-2003 Chevrolet Trailblazer?

    Yes, Dorman 526-633 is the front left lower control arm for the 2002-2003 Chevrolet Trailblazer. Other vehicles are covered too; look yours up in the "Vehicles it fits" section.

    Do I need to buy Dorman control arm bushings separately?

    No. This assembly comes with the ball joint and the steel and rubber bushings already installed on the arm, so no separate bushings are needed.

    What hardware comes with this Dorman control arm?

    Dorman 526-633 includes one control arm, one ball joint and one nut, plus mounting hardware. A grease fitting is not included.

    What size is the ball joint stud on this Dorman lower control arm?

    The stud is threaded, with a 16 mm thread diameter and a 34.58 mm stud length. The ball joint uses a press-in mounting.

    What can a worn front left lower control arm look or sound like?

    A clunk over bumps, uneven tire wear or cracked bushing rubber can all be signs of wear. A shop can check the ball joint for play, so have a suspected problem looked at promptly.
