TERREPOWER 42070 alternator for the 2015-2017 Chrysler 200 V6 3.6L and other vehicles is a remanufactured unit that charges the battery and powers the electrical system. The engine's serpentine belt turns it, and it supplies the 12-volt system while the engine runs.
- 160-amp rating at 12 volts DC
- Decoupler pulley with 6 grooves for serpentine belt drive
- Internal fan with air cooling
- External regulator; the alternator is not one-wire capable
- Clockwise (right) rotation
Quick facts
- Part: TERREPOWER 42070 alternator
- Fits: 2015-2017 Chrysler 200 V6 3.6L and other vehicles
- Condition: Remanufactured
Dim lights, a battery warning light or a battery that keeps going flat can mean the alternator is wearing out. Before you replace it, look over the drive belt and the battery cable ends with the engine off and cool; a cracked belt or a corroded terminal can produce similar trouble.
Fits
This is a direct-fit replacement alternator for the 2015-2017 Chrysler 200 V6 3.6L and the 2014-2022 Jeep Cherokee V6 3.2L, and each of them takes one.
Specifications
Fit and size
- Quantity per vehicle: 1
- Voltage: 12 V DC
- Amperage rating: 160 A
- Rotation direction: clockwise (right)
- Outside pulley diameter: 52 mm (2-1/16 in)
- Pulley grooves: 6
- Plug clock position (rear view, main mounting ear at 6 o'clock): 12
Build and materials
- Condition: remanufactured
- Regulator type: external
- Pulley: decoupler, serpentine belt type, included
- Cooling: air, with internal fan
- Ground type: negative
- One-wire capable: No; brushless: No; AC service tap: No
- Country of origin: Mexico
In the box
One alternator with its decoupler pulley.
Interchange: 421000-0820 · 421000-0821
56029622AB · 68271763AB
This part cross-references / interchanges with the following part numbers:
56029622AB, 68271763AB, 421000-0820, 421000-0821
Frequently Asked Questions
Is this the alternator for the 2015-2017 Chrysler 200 V6 3.6L?
Yes. TERREPOWER 42070 is listed for the 2015-2017 Chrysler 200 V6 3.6L, and that car takes one alternator.
Can I use this alternator for the 2014-2022 Jeep Cherokee V6 3.2L?
Yes. This alternator is listed for the 2014-2022 Jeep Cherokee V6 3.2L, one per vehicle.
What amperage and voltage is the TERREPOWER 42070 alternator?
TERREPOWER 42070 is rated 160 amps at 12 volts DC.
Does this alternator come with its pulley, and what type is it?
Yes. The pulley is included; it is a decoupler type with 6 grooves for a serpentine belt.
Is this alternator one-wire capable, and which way does it turn?
No, it is not one-wire capable; it uses an external regulator. It turns clockwise (right).
