Front CV Intermediate Shaft for 2015-2017 Hyundai Sonata & More - TrakMotive HY-3535

$106.99

Vehicles this part fits

    Part number: HY-3535
    UPC: 840140517125
    Condition: New
    Weight: 11.10 LBS
    Item Package Code: EA
    Part Has Core (Y/N): N
    Item Package Quantity: 1
    $106.99
    Adding to cart… The item has been added

    Have questions?

    TrakMotive CV Intermediate Shaft P/N:HY-3535
    TrakMotive CV Intermediate Shaft P/N:HY-3535
    $106.99
    $106.99

    TrakMotive HY-3535 front CV intermediate shaft for the 2015-2017 Hyundai Sonata and other vehicles carries drive torque toward the front right wheel. This is a new shaft.

    • 28 splines at the inboard end
    • 28 splines at the outboard end
    • Overall compressed length of 424 mm (16.69 in)
    • Front right position

    Quick facts

    • Part: TrakMotive HY-3535 CV intermediate shaft
    • Fits: 2015-2017 Hyundai Sonata and other vehicles
    • Position: Front, front right
    • Condition: New

    Clicking or clunking in turns, vibration under acceleration or a grease leak near the shaft can mean it is worn. A worn wheel bearing, a loose engine mount or a damaged outer axle joint can be behind the same signs, so find the source before you buy a shaft. This listing is one shaft for the front right; the other side is its own part and is ordered separately.

    Fits

    This shaft is a direct-fit replacement for the 2015-2017 Hyundai Sonata and the 2016-2020 Kia Optima.

    Specifications

    Fit and size

    • Position: front, front right
    • Quantity per application: 2 (2015-2017 Hyundai Sonata), 1 (2016-2020 Kia Optima)
    • Inboard splines: 28
    • Outboard splines: 28
    • Overall compressed length: 424 mm (16.69 in)

    Build and materials

    • Condition: new
    • Grade: Premium
    • Axle nut: not included
    • Warranty: TrakMotive limited lifetime warranty
    • Country of origin: China

    In the box

    One CV intermediate shaft. The axle nut is not included, so plan on a new one, since the old nut may not be reusable.

    Product information is for general reference and may contain errors. See our Disclaimer.

    This part cross-references / interchanges with the following part numbers:

    HY-3535

    Frequently Asked Questions

    Is the TrakMotive CV intermediate shaft HY-3535 a fit for the 2016-2020 Kia Optima?

    Yes. TrakMotive HY-3535 is a front right shaft listed for the 2016-2020 Kia Optima and for the 2015-2017 Hyundai Sonata.

    How many splines does the HY-3535 shaft have?

    This shaft has 28 splines at the inboard end and 28 at the outboard end. The overall compressed length is 424 mm (16.69 in).

    Does the HY-3535 CV intermediate shaft come with an axle nut?

    No. TrakMotive HY-3535 is sold as one new shaft, and the axle nut is not included.

    What warranty covers this TrakMotive shaft?

    TrakMotive backs this shaft with a limited lifetime warranty.

    What can clicking in turns mean on a front CV intermediate shaft?

    Clicking or clunking in turns, or vibration when accelerating, can mean wear in the shaft or its joints. Have it checked promptly, because the shaft drives the wheel.
