Delphi Suspension Control Arm and Ball Joint Assembly P/N:TC2590
Delphi TC6801 front left lower control arm with ball joint for the 2018-2022 Jeep Compass connects the front left wheel to the body and pivots at a ball joint.
Sold as a control arm and ball joint assembly, it replaces the arm and the joint in one piece. A worn strut, wheel bearing, tie rod end or sway bar link can cause a clunk over bumps, uneven tire wear or loose steering, just as a worn arm or joint can, so find the cause before buying.
This is a direct-fit replacement for the 2018-2022 Jeep Compass. The front axle takes one per side; this listing is the front left only, the front right is a separate part, and the other side of that axle is normally replaced at the same time.
Fit and size
Build and materials
Interchange: 68318 011AC · 68318 011AG · 68429 726AA · 68429 726AB
68318011AD · 68318011AE · 68318011AF · CMS251220
Product information is for general reference and may contain errors. See our Disclaimer.
This part cross-references / interchanges with the following part numbers:
Does the Delphi TC6801 control arm with ball joint fit the 2018-2022 Jeep Compass?
Yes, Delphi TC6801 is a front left lower control arm with ball joint for the 2018-2022 Jeep Compass. It is for the front left position only; the front right is a separate part.
How are the ball studs on this lower control arm made?
The ball studs on this control arm are machined to micron tolerances, which is meant to give durability and smooth joint operation.
What testing does the Delphi TC6801 go through?
Delphi TC6801 is tested below -40 degrees C and above 120 degrees C, with 720 hours of salt spray exposure. Each control arm also gets 100% crack detection and ultrasonic flaw detection.
What can a worn ball joint on a lower control arm feel like?
A clunk or knock over bumps, uneven tire wear or a loose steering feel can mean a worn joint. Because steering and suspension are involved, have a shop inspect it promptly.
Does Delphi TC6801 interchange with 68429 726AA?
Yes, 68429 726AA is one of the numbers Delphi TC6801 replaces, along with 68318 011AC and CMS251220. The full list is on the Interchange line.
