Delphi TC9415 front right upper control arm with ball joint for the 2021-2024 Mercedes-Benz Maybach S580 and other vehicles links the front suspension to the vehicle body and pivots on its ball joint. The ball joint is part of the arm, so one piece replaces both.
- Parts withstand temperatures below -40 degrees C and over 120 degrees C, plus 720 hours of salt spray
- Every control arm gets 100% crack detection and ultrasonic flaw detection
- Ball studs machined to micron tolerances for durability and smooth joint operation
- Robot-welded control arm for consistent performance and quality
- Anti-corrosion protection applied to each part
Quick facts
- Part: Delphi TC9415 control arm with ball joint
- Also called: control arm and ball joint assembly
- Fits: 2021-2024 Mercedes-Benz Maybach S580 and other vehicles
- Position: Front Right Upper
- Condition: New
A clunk over bumps, uneven front tire wear or loose steering can mean a worn arm or ball joint. Before ordering, look the arm over with the engine off for cracks or bends. Other suspension parts make similar noises, so have a shop test the joint if the arm looks sound.
Fits
The 2021-2024 Mercedes-Benz Maybach S580, 2021-2024 Mercedes-Benz S500 and 2021-2024 Mercedes-Benz S580 all take this arm, along with more vehicles, one per car at the front right upper position. Front arms are normally replaced in pairs; this listing is one arm, and the front left is a separate part.
Specifications
Fit and size
- Position: Front Right Upper
- Quantity per vehicle: 1
Build and materials
- Type: control arm with ball joint, one piece
- Corrosion protection: anti-corrosion protection on each part
- Condition: New
- Country of origin: Turkey
Interchange: 1028450 · 2233302600 · A2233302600
This part cross-references / interchanges with the following part numbers:
1028450, 2233302600, A2233302600
Frequently Asked Questions
Does the Delphi TC9415 fit the 2021-2024 Mercedes-Benz S500?
Yes. Delphi TC9415 fits the 2021-2024 Mercedes-Benz S500 as the front right upper arm, one per car. If your car is not named here, look it up in the "Vehicles it fits" section.
Where does this Delphi control arm go on the car?
This Delphi control arm goes in the front right upper position. The front left is a separate part with its own listing.
Is this control arm and ball joint assembly sold with the ball joint already attached?
Yes. Delphi TC9415 is one front right upper piece with the ball joint built into the arm.
What kind of temperature and salt testing do these control arms go through?
The parts withstand temperatures below -40 degrees C and over 120 degrees C and are exposed to 720 hours of salt spray. Anti-corrosion protection is applied to each one.
Is 2233302600 an interchange number for the Delphi TC9415?
Yes. 2233302600 is listed as an interchange number for Delphi TC9415, along with A2233302600 and 1028450.
