Rear Drive Shaft for 2017-2019 Nissan Titan XD - Dorman 986-682

$830.99

Vehicles this part fits

    Part number: 986-682
    UPC: 889245902887
    Condition: New
    Weight: 56.20 LBS
    Item Package Quantity: 1
    $830.99
    Adding to cart… The item has been added

    Have questions?

    Dorman - OE Solutions Drive Shaft P/N:986-682
    Dorman - OE Solutions Drive Shaft P/N:986-682
    $830.99
    $830.99

    Dorman 986-682 rear drive shaft for the 2017-2019 Nissan Titan XD carries engine torque from the transmission to the rear axle. This Dorman OE Solutions drive shaft is a rear 2-piece steel assembly in a standard replacement grade.

    • Drawn over mandrel (DOM) seamless steel tubing with uniform wall thickness and concentricity
    • Delivered fully assembled and dynamically pre-balanced
    • Pre-greased, greaseable shaft with a grease fitting and universal joints included
    • Slip yoke with 2.375 in of max slip lets the overall length adjust
    • Tubing, yokes and U-joints are all new components

    Quick facts

    • Part: Dorman 986-682 drive shaft
    • Fits: 2017-2019 Nissan Titan XD
    • Position: Rear
    • Material: Steel
    • Condition: New

    A worn drive shaft can show up as vibration that rises with speed, a clunk when shifting or accelerating, or grease thrown from the joints. Tires, wheels and other drivetrain parts can cause similar signs, so find the cause first: note whether the vibration follows road speed or only appears when shifting, and have a shop inspect the shaft and joints.

    Fits

    It fits the 2017-2019 Nissan Titan XD, which takes one rear drive shaft.

    Specifications

    Fit and size

    • Position: Rear
    • Quantity per vehicle: 1
    • Shaft diameter: 3.5 in
    • Wall thickness: 0.083 in
    • Overall length: 69.5 in
    • Collapsed length (flange face to flange face and yoke to flange face): 68.375 in
    • Collapsed length (yoke to bearing): 28.5 in
    • Max slip: 2.375 in
    • Ends: bolt on at both ends

    Build and materials

    • Construction: 2-piece driveshaft assembly with slip yoke
    • Material: Steel
    • Grade: Standard replacement
    • Pre-greased and greaseable, grease fitting included
    • Condition: New
    • Country of origin: United States

    In the box

    One drive shaft with its grease fitting and universal joints. CV joints and an axle nut are not included.

    Interchange: 37300EZ00A

    Product information is for general reference and may contain errors. See our Disclaimer.

    This part cross-references / interchanges with the following part numbers:

    37300EZ00A

    Frequently Asked Questions

    Does the Dorman 986-682 rear drive shaft fit the 2017-2019 Nissan Titan XD?

    Yes. Dorman 986-682 is a rear drive shaft listed for the 2017-2019 Nissan Titan XD, and that vehicle takes one.

    Does this drive shaft come with CV joints or an axle nut?

    No. The Dorman 986-682 package is one drive shaft with its grease fitting and universal joints. CV joints and an axle nut are not included.

    What are the length and tube diameter of this rear drive shaft?

    Overall length is 69.5 in and collapsed length is 68.375 in. The shaft diameter is 3.5 in, with a wall thickness of 0.083 in.

    Is this rear drive shaft made from seamless steel tubing?

    Yes. The shaft is steel, made from drawn over mandrel (DOM) seamless steel tubing.

    What can a worn rear drive shaft feel like while driving?

    Vibration that rises with speed, a clunk when shifting or accelerating, or grease thrown from the joints can all be signs of drive shaft wear. Other drivetrain parts can cause them too.
