Gates TCKWP306M timing belt kit with water pump for the 2000-2005 Volkswagen Jetta 4-cylinder 1.8L and other vehicles replaces the belt, tensioners and water pump in one job. A belt-driven water pump should be replaced along with the timing belt, and this engine timing belt kit with water pump covers both.
- Part of the Gates PowerGrip line of timing component kits with water pump
- Belt, tensioners and water pump supplied together, so the critical timing-system parts are replaced at the same time
- Hydraulic tensioner included, with its pulley attached
- Water pump designed and built for long-lasting, efficient cooling
- Belt made of HSN with fiberglass cord and curvilinear (II) teeth
Quick facts
- Part: Gates TCKWP306M timing belt kit with water pump
- Also called: engine timing belt kit with water pump
- Fits: 2000-2005 Volkswagen Jetta 4-cylinder 1.8L and other vehicles
- Material: HSN, fiberglass cord (belt)
- Condition: New
Coolant seepage around the water pump, a whine from the pump area or an engine running hot can point to parts in this kit, but they are also signs of other problems. With the engine off and cool, look for wet coolant residue near the pump to narrow it down before you buy.
Fits
It is listed for a wide range of Volkswagen and Audi models, including the 2000-2006 Volkswagen Golf 4-cylinder 1.8L and the 2000-2001 Volkswagen Passat 4-cylinder 1.8L. Driving something else? Look for your car in the "Vehicles it fits" section.
Specifications
Fit and size
- Quantity per vehicle: 1
- Belt width: 23 mm (0.906 in)
- Belt teeth: 150
- Tensioners: 2
- Water pump: 1
- Seal: 1
Build and materials
- Belt material: HSN, fiberglass cord
- Tensioner type: hydraulic
- Grade type: OE Performance
- Condition: New
- Country of origin: China
- Gates warranty: matches the original manufacturer's timing belt replacement intervals for parts, labor and other associated costs
In the box
One timing belt, two tensioners (one a hydraulic tensioner with its pulley attached), one water pump, one bolt, a bushing, an O-ring and one seal. An idler pulley, tensioner springs and an installation tool are not included. This listing is one kit, and each vehicle takes one.
Installation notes
- Detailed installation instructions come with the kit (instruction sheet 0098-1644).
- Technical Service Bulletins for troublesome applications are included.
Interchange: 3480-5306
PP306LK3MI · TB306LK4MI · PP306LK1MI · TB306LK1MI · WP306K2AM · 24441KM · BWPK41127DM · WPK41127DM
This part cross-references / interchanges with the following part numbers:
TCKWP306M, PP306LK3MI, TB306LK4MI, PP306LK1MI, TB306LK1MI, WP306K2AM, 3480-5306, 24441KM, BWPK41127DM, WPK41127DM
Frequently Asked Questions
Is this Gates timing belt and water pump kit right for the 2000-2005 Volkswagen Jetta 4-cylinder 1.8L?
Yes, Gates TCKWP306M is listed for the 2000-2005 Volkswagen Jetta 4-cylinder 1.8L, and the "Vehicles it fits" section shows the other models it covers.
Does TCKWP306M come with an idler pulley or tensioner springs?
No, Gates TCKWP306M has two tensioners, one of them hydraulic, but no idler pulley or tensioner springs; the water pump, bolt, bushing, O-ring and seal are in the kit.
How wide is the belt in this kit, and how many teeth does it have?
This timing belt is 23 mm (0.906 in) wide with 150 curvilinear (II) teeth. It is made of HSN with fiberglass cord.
Is a whine near the water pump a sign the pump in this kit is wearing?
It can be a sign of wear, but other parts can make a similar noise. Coolant residue near the pump or an engine running hot are other signs worth having a shop look at.
Do installation instructions come with this timing belt kit?
Yes, Gates TCKWP306M includes detailed installation instructions (sheet 0098-1644) and Technical Service Bulletins for troublesome applications.
