Timing Belt Kit with Water Pump for 2006-2009 Subaru Outback & More - Gates TCKWP307AN

$373.99

Vehicles this part fits

    Part number: TCKWP307AN
    UPC: 770075707516
    Condition: New
    Weight: 9.30 LBS
    Item Package Quantity: 1
    $373.99
    Adding to cart… The item has been added

    Have questions?

    Gates Engine Timing Belt Kit with Water Pump P/N:TCKWP307AN
    Gates Engine Timing Belt Kit with Water Pump P/N:TCKWP307AN
    $373.99
    $373.99

    Gates TCKWP307AN timing belt kit with water pump for the 2006-2009 Subaru Outback H4 2.5L and other vehicles replaces the timing belt, tensioner, idlers and water pump in a single job. A timing belt drives the water pump, so the two should be replaced at the same time.

    • PowerGrip Premium Timing Component Kit with Water Pump product line
    • Kit holds the timing belt, one hydraulic tensioner, three idlers and the water pump
    • Timing belt with HSN, fiberglass cord and timing marks; 223 teeth, curvilinear (II) tooth type, 27 mm wide
    • Water pump designed and built for efficient cooling

    Quick facts

    • Part: Gates TCKWP307AN timing belt kit with water pump
    • Also called: engine timing belt kit with water pump
    • Fits: 2006-2009 Subaru Outback H4 2.5L and other vehicles
    • Material: HSN, fiberglass cord (belt)
    • Condition: New

    Coolant seepage near the water pump, a ticking or rattle from the belt area, or rough running can point to a worn component in this kit. Cooling hoses, a leaking radiator or an ignition fault can be behind some of these signs as well, so find the cause before buying.

    Fits

    It is a direct-fit timing belt kit with water pump for the 2006-2009 Subaru Legacy H4 2.5L and for the 2006-2009 Subaru Outback H4 2.5L.

    Specifications

    Fit and size

    • Quantity per vehicle: 1 kit
    • Components: 6 (1 belt, 1 tensioner, 3 idlers, 1 water pump)
    • Timing belt width: 27 mm (1.063 in)
    • Timing belt teeth: 223

    Build and materials

    • Tensioner type: Hydraulic
    • Belt material: HSN, fiberglass cord
    • Tooth type: Curvilinear (II)
    • Grade: OE Exact
    • Condition: New
    • Warranty: Gates warranty matches the original manufacturer's timing belt replacement intervals, covering parts, labor and other associated costs
    • Country of origin: Japan

    In the box

    One timing belt, one hydraulic tensioner, three idlers, one water pump, an installation tool, Loctite, one metal gasket, one O-ring and detailed installation instructions. This listing is one kit, and the vehicle takes one. Bolts and springs are not included, so plan on new bolts.

    Installation notes

    • Detailed installation instructions come with the kit (instruction sheet 0098-1683).
    • Technical Service Bulletins for troublesome applications are included.

    Interchange: 24541KN

    Product information is for general reference and may contain errors. See our Disclaimer.

    This part cross-references / interchanges with the following part numbers:

    24541KN

    Frequently Asked Questions

    Is TCKWP307AN the right kit for the 2006-2009 Subaru Outback H4 2.5L?

    Yes. Gates TCKWP307AN fits the 2006-2009 Subaru Outback H4 2.5L, and it also fits the 2006-2009 Subaru Legacy H4 2.5L. Each takes one kit.

    Does this Gates timing belt and water pump kit include a tensioner and idlers?

    Yes. Gates TCKWP307AN has one hydraulic tensioner, three idlers, one belt and one water pump, plus an installation tool, Loctite, a metal gasket and an O-ring. Bolts and springs are not included.

    How wide is the timing belt in this kit, and how many teeth does it have?

    The belt is 27 mm (1.063 in) wide with 223 teeth and a curvilinear (II) tooth type. Its belt material is HSN with fiberglass cord.

    Does this engine timing belt kit with water pump come with installation instructions?

    Yes. Detailed instructions come in the kit (sheet 0098-1683), along with Technical Service Bulletins for troublesome applications. An installation tool is included as well.

    Does 24541KN cross-reference to Gates TCKWP307AN?

    Yes. 24541KN is listed as an interchange number for Gates TCKWP307AN.
