Gates 52059 heater hose for the 2015 Dodge Charger V8 6.4L, the 2015-2023 Charger V8 5.7L and other vehicles carries engine coolant through the heater circuit. This Gates HVAC heater hose is a modular assembly made with OEM-exact hose components.
- Molded construction: EPDM tube, synthetic fiber knit reinforcement and a heat-, ozone- and chemical coolant-resistant EPDM cover
- Specifically-engineered materials resist collapse under vacuum
- Engineered to resist electrochemical degradation, the leading cause of hose failure
- Modular assembly with 2 branches
- Temperature range: -40°F to +257°F (-40°C to +125°C)
- Meets SAE 20R3 EC Class D1 under 25 mm (1 in.) ID and SAE 20R4 EC Class D1 for 25 mm (1 in.) ID and over
Quick facts
- Part: Gates 52059 heater hose
- Also called: HVAC heater hose
- Fits: the 2015 Dodge Charger V8 6.4L, the 2015-2023 Charger V8 5.7L and other vehicles
- Position: Heater outlet
- Material: EPDM
- Condition: New
Coolant seepage at the hose ends, a cracked, swollen or soft cover, or weak cabin heat can mean a heater hose is wearing out. Before you replace this one, rule out the heater core, the thermostat and the coolant level (check it only on a cool engine) so you correct the real cause.
Fits
It fits the 2015 Dodge Charger V8 6.4L and the 2015-2023 Charger V8 5.7L, the 2015-2016 and 2018-2023 Chrysler 300 V8 5.7L, and the 2015 Dodge Challenger V8 6.4L and the 2015-2023 Challenger V8 5.7L. This listing is one hose for the heater outlet, and that position takes a single hose per car.
Specifications
Fit and size
- Position: heater outlet
- Quantity per vehicle: 1
- Centerline length: 25 in (635 mm)
- End 1 inside diameter: 15 mm (0.59 in)
- End 2 inside diameter: 18 mm (0.72 in)
- End 3 inside diameter: 0.72 in
- Branches: 2
Build and materials
- Material: EPDM
- Construction: molded, modular
- Internal spring: none
- Condition: New
- Country of origin: United States
In the box
One modular heater hose with its two branches.
Installation notes
- Replace the clamps each time a new coolant hose is installed.
- Do not use this hose for fuel or oil transfer.
Interchange: 626-335
68193882AD · F11381
Product information is for general reference and may contain errors. See our Disclaimer.
This part cross-references / interchanges with the following part numbers:
68193882AD, 626-335, F11381, 52059
Frequently Asked Questions
Is this a heater hose for the 2015 Dodge Charger V8 6.4L and the 2015-2023 Charger V8 5.7L?
Yes. Gates 52059 fits the 2015 Dodge Charger V8 6.4L and the 2015-2023 Charger V8 5.7L. It is the heater outlet hose, and each car takes one.
Will this work as a heater hose for the 2018-2023 Chrysler 300 V8 5.7L?
Yes. Gates 52059 fits the 2018-2023 Chrysler 300 V8 5.7L, and the 2015-2016 Chrysler 300 V8 5.7L as well. It goes in the heater outlet position.
What is this Gates molded heater hose made of?
Both the tube and the cover are EPDM, and the reinforcement is a synthetic fiber knit.
What temperature range does this heater hose handle?
Gates 52059 covers -40°F to +257°F (-40°C to +125°C). Do not use it for fuel or oil transfer.
Do I need new clamps with this heater hose?
Yes. Clamps should be replaced each time a new coolant hose is installed, so plan on fresh ones rather than reusing the old clamps.
