Spark Plug for 1980-1996 Ford F-150 & More - NGK UR5GP

$8.99

Vehicles this part fits

    Part number: UR5GP
    UPC: 087295135471
    Condition: New
    Weight: 0.09 LBS
    Item Package Quantity: 1
    $8.99
    Adding to cart… The item has been added

    Have questions?

    NGK Spark Plug P/N:UR5GP
    NGK Spark Plug P/N:UR5GP
    $8.99
    $8.99

    NGK UR5GP spark plug for the 1980-1985 Ford F-150 V8 5.0L, the 1984-1996 F-150 V8 5.8L and other vehicles is one of the NGK spark plugs that ignite the air-fuel mixture in each cylinder. It is a single platinum plug, and its recommended use is as an upgrade for engines that originally ran nickel alloy plugs.

    • NGK G-Power Platinum line with a single platinum tip
    • Fine wire 0.6 mm platinum tip on the center electrode for a consistently stable spark
    • Trapezoidal cut ground electrode with a reduced-quenching design for improved ignitability
    • Solid copper core, 98% pure copper, for heat dissipation and conductivity
    • Cold-rolled threads that help prevent cross-threading and damage to cylinder heads

    Quick facts

    • Part: NGK UR5GP spark plug
    • Fits: 1980-1985 Ford F-150 V8 5.0L, the 1984-1996 F-150 V8 5.8L and other vehicles
    • Condition: New

    Hard starting, a misfire or a rough idle can mean worn plugs, but the ignition wires or the fuel injectors may be the cause, so find the source before you replace anything. The 1988-1995 Chevrolet C1500 V6 4.3L takes six plugs, and its V8 engines take eight.

    Fits

    Among the vehicles this plug fits are the 1988-1995 Chevrolet C1500 V6 4.3L, V8 5.0L or 5.7L, the 1990-1993 C1500 V8 7.4L and the 1988-1995 Chevrolet K1500 V6 4.3L, V8 5.0L or 5.7L. If your vehicle is not named here, look up your year and engine in the "Vehicles it fits" section.

    Specifications

    Fit and size

    • Thread: 14 mm (M14 - 1.25)
    • Reach: 0.460 in (11.2 mm)
    • Seat: tapered
    • Quantity per vehicle: 4, 6 or 8, depending on the engine

    Build and materials

    • Type: single platinum
    • Center electrode: fine wire platinum tip
    • Ground electrode: trapezoidal cut
    • Core: solid copper
    • Resistor: yes
    • NGK stock number: 3547
    • Condition: New

    Interchange: 3547

    Product information is for general reference and may contain errors. See our Disclaimer.

    This part cross-references / interchanges with the following part numbers:

    3547

    Frequently Asked Questions

    Is NGK UR5GP a Ford F-150 spark plug for the 1980-1985 F-150 V8 5.0L or the 1984-1996 F-150 V8 5.8L?

    Yes. NGK UR5GP fits the 1980-1985 Ford F-150 V8 5.0L and the 1984-1996 F-150 V8 5.8L, and both engines take eight plugs.

    Do these K1500 spark plugs fit the 1988-1995 Chevrolet K1500 V6 4.3L, V8 5.0L or 5.7L?

    Yes. NGK UR5GP fits the 1988-1995 Chevrolet K1500 with the V6 4.3L, V8 5.0L or V8 5.7L, taking six plugs for the V6 and eight for the V8 engines.

    Is this one of the NGK iridium spark plugs?

    No. This listing is the NGK G-Power Platinum UR5GP with a single platinum tip, and iridium plugs are separate NGK parts.

    Is the NGK Iridium IX spark plug an upgrade from the G-Power Platinum UR5GP?

    Yes. The NGK Iridium IX plug is the step up from this G-Power Platinum plug for better performance, and this listing is the single platinum UR5GP only.

    What thread size and reach does the NGK UR5GP have?

    The NGK UR5GP has a 14 mm thread (M14 - 1.25), a 0.460 in (11.2 mm) reach and a tapered seat. It is a resistor plug.
