TERREPOWER 99P17799A rear right brake caliper for the 2019-2024 Ram 2500 and other vehicles squeezes the brake pads against the rotor to slow the wheel. This caliper is remanufactured and made for the rear right wheel only.
- Floating caliper design with two pistons
- Phenolic pistons with a 48 mm (1.89 in) outside diameter
- Cast iron housing with an E-coated finish
- Banjo bolt inlet fitting with an M10-1.0 thread
Quick facts
- Part: TERREPOWER 99P17799A brake caliper
- Also called: disc brake caliper
- Fits: 2019-2024 Ram 2500 and other vehicles
- Position: Rear right
- Material: Cast iron
- Condition: Remanufactured
A rear caliper that sticks or leaks can show up as the vehicle pulling to one side when braking, uneven pad wear or fluid around the piston boot. Those signs can have other sources, so find the actual fault before replacing a disc brake caliper. During a brake service, look at the boot and pads with the engine off.
Fits
This brake caliper for the 2019-2025 Ram 3500 also fits the 2019-2024 Ram 2500. The rear right takes one caliper, and this listing is that one; the rear left is a separate part, and the two sides are normally replaced together.
Specifications
Fit and size
- Position: Rear right
- Quantity per application: 1
- Piston outside diameter: 48 mm (1.89 in)
- Inlet fitting: banjo bolt, M10-1.0 thread
- Bleeder screw: M10-1.0 x 28
Build and materials
- Caliper type: Floating
- Pistons: 2, phenolic
- Casting material: Cast iron
- Finish: E-coated
- Condition: Remanufactured
- Country of origin: Mexico
In the box
One remanufactured rear right brake caliper with its bracket, slides, dust boots, caliper and pad hardware, bleeder screw and crush washers. Brake pads, anti-squeal shims, wear sensors, the bleeder screw cap and bracket mounting bolts are not included; plan on new bracket bolts.
Interchange / FMSI:
FMSI: D2225
Frequently Asked Questions
Is this a brake caliper for the 2019-2024 Ram 2500?
Yes. TERREPOWER 99P17799A is a rear right caliper for the 2019-2024 Ram 2500 and the 2019-2025 Ram 3500.
Does this rear right caliper come with a bracket and brake pads?
TERREPOWER 99P17799A includes the bracket, slides, dust boots and hardware, but brake pads are not included. Bracket mounting bolts are not included either.
Is this caliper a floating or fixed design?
Floating. This rear caliper has two phenolic pistons with a 48 mm (1.89 in) outside diameter and a cast iron housing with an E-coated finish.
How can I tell if the rear right caliper is leaking or sticking?
Brake fluid around the piston boot, uneven pad wear or the vehicle pulling to one side under braking can be signs. A shop can test a caliper that sticks.
Which brake line connection does this rear right caliper use?
It uses a banjo bolt inlet with an M10-1.0 thread, and crush washers are included. Opening a brake line is best left to a shop.
