Clutch Flywheel for 2008-2012 Honda Accord & More - Sachs NFW9135

$352.99

Vehicles this part fits

    Part number: NFW9135
    UPC: 708609482219
    Condition: New
    Weight: 20.60 LBS
    Item Package Quantity: 1
    $352.99
    Adding to cart… The item has been added

    Have questions?

    Sachs Clutch Flywheel P/N:NFW9135
    Sachs Clutch Flywheel P/N:NFW9135
    $352.99
    $352.99

    Sachs NFW9135 clutch flywheel for the 2008-2012 Honda Accord and other vehicles bolts to the crankshaft and gives the clutch a flat friction surface. Its ring gear is what the starter turns to start the engine.

    • Cast iron flywheel body
    • Ring gear with 119 teeth and a 306 mm outside diameter
    • Flat friction surface set 18 mm from the cover
    • Eight pressure plate mounting holes of 8 mm and three 6 mm dowel pins
    • External engine balance

    Quick facts

    • Part: Sachs NFW9135 clutch flywheel
    • Fits: 2008-2012 Honda Accord and other vehicles
    • Material: Cast iron
    • Condition: New

    Chatter, shudder or slipping as the clutch engages can mean the flywheel face is worn, though a worn clutch disc or a weak pressure plate can sit behind those signs too, so find which part is at fault before ordering.

    Fits

    This listing is one flywheel. It is a direct-fit replacement for the 2008-2012 Honda Accord and the 2009-2014 Acura TSX, and each of them takes one. It is matched for OE form, fit and function.

    Specifications

    Fit and size

    • Quantity per vehicle: 1
    • Ring gear outside diameter: 306 mm
    • Ring gear teeth: 119
    • Mounting hole diameter: 12.5 mm
    • Flywheel-to-crankshaft bolts: 8
    • Pressure plate mounting holes: 8, 8 mm diameter
    • Dowel pins: 3, 6 mm diameter
    • Friction surface distance to cover: 18 mm

    Build and materials

    • Material: Cast iron
    • Friction surface: flat, not replaceable
    • Engine balance: external
    • Grade: standard replacement
    • Condition: New
    • Country of origin: Japan

    Interchange: 22100R40003

    Product information is for general reference and may contain errors. See our Disclaimer.

    This part cross-references / interchanges with the following part numbers:

    22100R40003

    Frequently Asked Questions

    Is the Sachs NFW9135 a Honda Accord clutch flywheel for the 2008-2012 model years?

    Yes. Sachs NFW9135 fits the 2008-2012 Honda Accord and the 2009-2014 Acura TSX, and each of them takes one flywheel.

    What is the Sachs NFW9135 flywheel made of?

    The Sachs NFW9135 is cast iron. Its ring gear has 119 teeth and a 306 mm outside diameter.

    Does this flywheel have a replaceable friction surface?

    No. The friction surface is flat and is not a replaceable one. The flywheel is also externally balanced.

    What can I check on a clutch flywheel when the clutch is out?

    During clutch service, look at the friction face for grooves, cracks or heat marks, which can mean wear. While driving, shudder or slipping as the clutch engages is what you may notice.

    Does Sachs NFW9135 replace interchange number 22100R40003?

    Yes. 22100R40003 is listed as an interchange number for the Sachs NFW9135 clutch flywheel.
