Melling Performance Engine Oil Pump Pickup Tube and Screen P/N:12564
$48.99
(You save)
Feed your oil pump a steady, screened supply with the Melling Performance Engine Oil Pump Pickup Tube and Screen 12564. On the suction side of the lubrication system, this pickup draws oil from the pan sump and strains out debris and contaminants — from normal engine wear, extended oil-change intervals, and other internal sources — before that oil ever reaches the pump. It's a direct-fit replacement for a wide range of GM V8 applications, including the 1988-1999 Chevrolet C1500 and K1500 [V8-5.7L], 1957-1975 Chevrolet Bel Air, and 1990-1992 Cadillac Brougham [V8-5.7L]. See the Buyer's Guide tab for the full list of 492 applications.
Galvanized steel screen: guards the pump from materials that find their way into the oil supply.
Straight tube: 8.500 in (216 mm) long with a 0.750 in (19 mm) inside diameter and a flanged end using 2 mounting holes.
Adjustable pickup: screen height adjusts up to 0.250 in (6.35 mm) for proper sump clearance.
Gasket included; protective coating applied. Built to OE-level tolerances. Mounting hardware is not included — consult the vehicle service information for the correct fasteners.
Melling recommends fitting a fresh high-performance pickup tube/screen as part of every oil pump installation. Made in the United States.
Frequently Asked Questions
What does this oil pump pickup tube and screen do?
It sits on the suction side of the lubrication system, drawing oil from the pan sump and straining out debris before the oil reaches the pump, helping protect the pump from contaminants.
Is mounting hardware included?
No. Mounting hardware is not included. A gasket or seal is included. Consult your vehicle service information for the correct mounting fasteners and torque specs.
What are the tube dimensions?
The straight tube is 8.500 in (216 mm) long with a 0.750 in (19 mm) inside diameter and a flanged end with 2 mounting holes. The screen adjusts up to 0.250 in (6.35 mm).
What is the screen made of?
The pickup screen is galvanized steel, and the assembly is supplied with a protective coating. It is a Performance-grade unit made in the United States.
Will this fit my vehicle?
It fits many GM V8 applications such as the 1988-1999 Chevrolet C1500 and K1500 [V8-5.7L]. Check the Buyer's Guide tab to confirm your exact year, make, model, and engine among the 492 applications.
